Philips BDP7500B2 - Analog Video Performance; CVBS Output Component Specs; Component Video Output Specs; Digital Input Specifications

Technical Speci¿cations and Connection Facilities
1.6 Analog Video Preformance
1.6.1 CVBS Output Component
Amplitude Output : 1000mVpp ± 10%
White Bar : 714mVpp ± 10%
Sync. Amplitude : 286mVpp ± 10%
61/XPLQXQFHG%
'&/HYHO9
Chroma / Luminunce Delay(2T pulse)
QV
Amplitude Output : 1000mVpp ± 10%
White Bar : 714mVpp ± 10%
Sync. Amplitude : 286mVpp ± 10%
61/XPLQXQFHG%
'&/HYHO9
Chroma / Luminunce Delay(2T pulse)
QV
1.6.2 Video Output Component
COMPONENT VIDEO OUT – Cinch (Y/Pb/Pr):
According to EIA-770-1-A, EIA-770-2-A
1.7 Digital Inputs
1.7.1 (AUDIO OUT) COAXIAL DIGITAL OUT – Cinch
LPCM : according IEC 60958-3
MPEG 1, MPEG 2, AC3 : according IEC 61937
DTS : according IEC 61937 +
addendum
1.7.2 USB
Compatibility : USB 2.0
Type of connector : Series A Connector
1.7.3 HDMI Output
Compatibility : HDMI version 1.3
Type of connector : Type A connector
(19 pins)
1.8 Video Performance
1.8.1 SNR
PAL
RGB CVBS Y/C
G% /XPLQFDQFHG%
&KURPDG%$0
G%30
YG%
&G%$0
G%30
NTSC
Y Pb Pr CVBS Y/C
G% /XPLQFDQFHG%
&KURPDG%$0
G%30
YG%
&G%$0
G%30
1.8.2 Bandwidth
PAL
RGB CVBS Y/C
0.5 to 4 MHz:+1dB/
-2dB
0.5 to 4 MHz:+1dB/
-2dB
Y:4.8MHz-3dB
4.8 MHz:-3dB 4.8 MHz:-3dB C:700 kHz
5.8 MHz:-6dB 5.8 MHz:-6dB
NTSC
YPbPr CVBS Y/C
4.2 MHz:-3dB 4.2 MHz:-3dB Y:4.2MHz-3dB
5.8 MHz:-6dB 5.8 MHz:-6dB &N+]
With Pscan:
8.4MHz -3dB
1-2
