SERVICE MANUAL
LBB 3310/00, 3330/00 and 3331/00 page: 8 Date of issue:
4822 861 11006 July 1998
Line regulation
Line input Load Regulation
Input change 90 .. 264Vac 1.7A < ±1%
Ripple and noise
Output Test Conditions
24V with 1.7A load <1% p-p (rated load) Oscilloscope with 15Mhz
limited bandwidth
AC input pin assignment K1 1 . 3
LN
Line Neutral
AC input fuse F1
Replace power supply unit in case of fuse failure!
DC output pin assignment K2 123456
+24V +24V +24V GND GND GND
7.4 Additional information
For more technical data about the CCS 800 refer to ‘Instructions for use’, chapter 8.
