English
35
Tape Operation/Recording
IMPORTANT!
– Before playing a tape, check and
tighten slack tape with a pencil. Slack
tape may get jammed or may burst in
the mechanism.
– Store tapes at room temperature and
do not put them too close to a magnetic
field (for example, a transformer, TV set
or speaker).
Tape playback
● Only cassette keys can be used for tape playback
control.
1 Press 70 to open the tape deck door.
2 Insert a recorded tape and close the tape door.
● Load the tape with the open side down and the
full spool to the left.
2 Press TAPE on the front panel to select tape
mode, and then press 3 to switch to TAPE
source.
4 Press 3 to start playback.
Interrupting playback
● Press 8 to interrupt playback.
Stopping playback
● Press 70 to stop playback.
Rewinding or forwarding fast when
playback is stopped
1 Press 1 or ¡.
2 Press 70 when you reach the desired passage.
General information on
recording
● If you don’t intend to record via the microphone,
unplug it to avoid unwanted recording source.
● For recording, only use tape of IEC type I(normal
tape).
● The recording level is set automatically,
regardless of the position of the Volume, Vocal,
Key control and so forth.
● The type is secured at both ends with leader
tape. At the beginning and end of the tape,
nothing will be recorded for seven seconds.
● To prevent accidental recording, break out the
tab on the left shoulder of the tape side you
want to protect.
● Press ● in Disc/USB, Tuner/AUX mode, the
record key ● can’t be pressed if there is no
recordable tape in tape deck .
FWD397-98_UM ENG_0514 2008.5.14, 15:5335
