Philips FWM390 - Location of PC Boards

1-2
LOCATION OF PC BOARDS
/21 /22 /25 /30
Karaoke
News x x
RDS x x
Rotary Encoder (volume control) x x x x
Jog Shuttle x x x x
Voltage Selector x
Aux Input x x x x
Digital Output
Headphone Socket x x x x
Line Output
Matrix Surround Loudspeakers
Standby - FTD Clock Display x x
ECO Standby - Dark x x
ECO6 Tuner board - System Non-Cenelec x x
ECO6 Tuner board - System Cenelec x x
ETF7 Tape Module: Non-Autoreverse Ferro x x x x
POWER 2001 Module (30-70W Version): x x x x
VERSION VARIATIONS:
Type /Versions: FWM390
Features &
Board in used:
ETF7
BOARD
MAINS
BOARD
LEFT/RIGHT AMPLIFIER
& SUPPLY BOARD
MAINS SOCKET
BOARD
TUNER
BOARD
CD KEY BOARD
FRONT
BOARD
KARAOKE
BOARD
AF9
BOARD
HEADPHONE
BOARD
CD
BOARD
