SCREW LISTS - MAIN UNIT
185 D3 x 12
186 D3 x 12
211 D3 x 12
212 D3 x 12
213 D3 x 12
214 D3 x 12
215 D3 x 12
226 M3 x 6
227 M3 x 10
229 M3 x 10
230 D3 x 10
231 M3 x 10
232 M3 x 6
276 M3 x 6
277 M3 x 10
278 D3 x 16
279 D3 x 12
280 D3 x 12
283 D3 x 12
287 D3 x 12
292 D3 x 12
293 D3 x 12
294 M3 x 10
295 D3 x 12
296 D3 x 12
297 D3 x 12
299 D3 x 12
300 D3 x 12
301 D3 x 12
302 D3 x 12
304 D3 x 12
M
ECHANICAL PARTSLIST ACCESSORIES
101 3140 117 71061 CAB FRONT /21/30 350 3140 118 51711 BOX SPK ASSY
101 3140 117 71051 CAB FRONT /22/25 351 4822 303 50063 FM ANTENNA
103 3140 117 69751 COVER FRONT CDC /21/30 356 3139 238 06131 REMOTE CONTROL
103 3140 117 71831 COVER FRONT CDC /22/25 384 2422 549 45067 ANT AM LOOP LAN-006 B
105 3140 117 64710 BTN SET C/CDC SEL /21/30 385 2422 070 98151 MAINSCORD /21/22
105 3140 117 64540 BTN SET CDC LPS C390 /22/25
385 2422 070 98248 MAINSCORD /30
106 3140 117 71021 COVER TRAY CDC
386 4822 263 21092 ADAPTER PLUG /21
107 3140 117 69761 BUTTON SET OPEN/CLOSE
108 4822 454 13408 BADGE PHILIPS
128 3140 117 69771 WINDOW DISPLAY /21/30
128 3140 117 69891 WINDOW DISPLAY /22/25
1201 3139 110 34600 FFC FOIL /21/22/30
1300 3139 110 35350 FFC FOIL 11P/220/11P AD
129 3140 117 69781 COVER FRONT DISPLAY
1400 3139 110 35110 FFC FOIL 04P/220/04P AD
130 3140 117 69791 COVER FRONT ORNA.
1401 4822 320 12703 7P - 140MM
131 3139 114 71350 LIGHTGUIDE SOURCE SELECT
1402 3139 110 35100 FFC FOIL 19P/140/19P AD
132 3140 117 69801 BUTTON SET SOURCE
1403 3139 110 34610 FFC FOIL 11P/180/11P AD
134 3140 117 71031 BTN SET C/PROG N VCD
1500 3139 110 33960 FFC FOIL 04P/120/04P BD
135 3140 117 69811 BUTTON MAX
1501 3139 110 33960 FFC FOIL 04P/120/04P BD /21
136 3140 117 69822 BUTTON DSC/DBB/VEC/IS
1600 3139 110 35050 FFC FOIL 08P/220/08P AD
137 3140 117 71071 RING VOLUME
1700 4822 320 12752 7P - 180MM
138 3139 118 16230 KNOB ROTARY
1800 3139 110 35880 FFC FOIL 15P/180/15P BD
139 3139 118 13190 KNOB VOLUME CHROME
5001 3103 308 30640 TRANSF. MAINS /21
140 3139 114 71330 LIGHTGUIDE DSC/DBB/VEC/IS
5001 3103 308 30630 TRANSF. MAINS /22/25/30
142 3140 117 64750 BUT SET RDS/NEWS /22/25
158 3140 117 69851 COVER CASS RIGHT
159 3140 117 69861 COVER CASS LEFT
160 3140 117 69871 LENS CASS RIGHT
161 3140 117 69881 LENS CASS LEFT
197 3139 114 68630 DOOR CASSETTE RIGHT ETF
198 3139 114 68620 DOOR CASSETTE LEFT ETF
199 4822 402 10621 PUSH-CATCH
200 4822 529 10322 DAMPER ASSY
201 3139 114 68640 PUSH CATCH LEFT
203 4822 492 11344 SPRING COMPRESSION
204 4822 402 11246 BRACKET RIGHT
205 4822 402 11245 BRACKET LEFT
206 3139 111 01380 SPRING TORSION RIGHT
207 3139 111 01390 SPRING TORSION LEFT
Note: Only these parts mentioned in the list are
209 4822 492 42787 SPRING CASSETTE
normal service parts.
242 4822 462 40683 RUBBER FOOT
251 3139 114 70970 BRACKET CDC LEFT
252 3139 114 70980 BRACKET CDC RIGHT
253 3139 114 73570 PANEL LEFT
254 3139 114 73580 PANEL RIGHT
255 3139 114 73590 COVER TOP
256 3140 114 63231 PANEL REAR /21/30
256 3140 114 63241 PANEL REAR /22/25
271 3139 114 71010 STOPPER HEATSINK
!
!
!
!
!
385 2422 070 98147 MAINSCORD /25
!
