Mode No 20 21 22 23 24 25 26 27 28
H Resolution: 1280 1920 640 852 640 832 1152 1366 1360
V Resolution: 720p 1080i 350 480 480 624 870 768 768
Refresh Rate: 60 60i 70 60 67 75 75 60 60 Hz
Pixel Clock: 74.250 74.250 25.175 30.000 30.240 57.283 100.000 85.383 72.000 MHz
Horizontal visible: 1280 1920 640 852 640 832 1152 1366 1360 Dots
Horizontal total: 1650 2200 800 955 864 1152 1456 1790 1520 Dots
Horizontal front porch: 110 88 16 19 64 32 32 100 48 Dots
Horizontal sync: 40 44 96 48 64 64 128 112 32 Dots
Horizontal back porch: 220 148 48 36 96 224 144 212 80 Dots
Horiz blanking time: 370 280 160 103 224 320 304 424 160 Dots
Vertical visible: 720 540 350 480 480 624 870 768 768 Lines
Vertical total: 750 562.5 449 525 525 667 915 795 790 Lines
Vertical front porch: 5 3 37 10 3 1 3 1 2 Lines
Vertical sync: 5 5 2 2 3 3 3 3 5 Lines
Vertical back porch: 20 15 60 33 39 39 39 23 15 Lines
Vertical blanking time: 30 23 99 45 45 43 45 27 22 Lines
Horizontal frequency: 45.000 33.750 31.469 31.413 35.000 49.725 68.681 47.700 47.368 KHz
Vertical frequency: 60.000 60.000 70.087 59.835 66.667 74.550 75.062 60.000 59.960 Hz
Vertical sync polarity: + + - - - - - - - TTL
Horiz sync polarity: + + + - - - - - + TTL
Mode No 29 30 31
H Resolution: 848 1280 1280
V Resolution: 480 960 960
Refresh Rate: 60 60 85 Hz
Pixel Clock: 29.875 108.000 148.500 MHz
Horizontal visible: 848 1280 1280 Dots
Horizontal total: 1008 1800 1728 Dots
Horizontal front porch 48 96 64 Dots
Horizontal sync: 32 112 160 Dots
Horizontal back porch: 80 312 2 24 Dots
Horiz blanking time: 160 520 448 Dots
Vertical visible: 480 960 960 Lines
Vertical total: 494 1000 1011 Lines
Vertical front porch: 2 1 1 Lines
Vertical sync: 5 3 3 Lines
Vertical back porch: 7 36 47 Lines
Vertical blanking time: 14 40 51 Lines
Horizontal frequency: 29.640 60.000 85.938 KHz
Vertical frequency: 60.000 60.000 85.002 Hz
Vertical sync polarity: - + + TTL
Horiz sync polarity: + + + TTL
