15”TFT XGA LCD CMTR
TYPE : AJ6S40/02
BRAND : HP (L1502)
2003-08-11
8639 000 14754
13
590
18
5.7 Panel Defect Limits
This is general specification from HP, if any deviation, HP agree to follow up panel specification.
Table 9 lists the countable and rejectable sizes for each type of commonly found defects. Defects
within the countable size are allowed; however, the total number of countable defects shall not
exceed the maximum number of all countable defects noted in the table. Any defect with dimensions
greater than the countable defect shall be sufficient cause for rejecting the display.
The symbols used are: D = Diameter, L = Length (longest dimension), W = Width (perpendicular to
the length), N = Number or Count, Spot = Contamination, S = Separation from Edge to Edge, Dot =
Sub-pixel stuck on/off (electrical).
TABLE 9
OPTO-MECHANICAL DEFECTS
VISUAL DEFECTS: (See Notes) COUNT REJECT
Dark/White Spot
0.25 < D £ 0.40, N £ 3
D > 0.40 or N > 3
Bright Line (Light Lint)
0.03 < W £ 0.152, L £ 2.03, N £ 4
W > 0.152 or L > 2.03 or N > 4
Dark Line (Dark Lint/Hair)
0.03 < W £ 0.10, 0.3 < L £ 1.0, N £ 4
W > 0.10 or L > 1.0 or N > 4
Polarizer Scratch
0.01 < W £ 0.07, 1.0 < L £ 10.0, N £ 3
W > 0.07 or L > 10.0 or N > 3
Polarizer Dents
0.15 < D £ 0.4, N £ 3
D > 0.4 or N > 3
Polarizer Bubble
0.254 < D £ 0.40, N £ 3
D > 0.40 or N > 3
Rubbing Defects Not Allowed
Newton Rings Not Allowed
Mottling Not Allowed
ELECTRICAL DEFECTS: (See Notes)
Bright Dot (Electrical):
High and Low Level (Total)
N £ 3
N>3
Dark Dot (Electrical)
N £ 5
N>5
Minimum Distance Between Electrical Defects
High Level Green to High Level Green
S ³ 25.4
S<25.4
Bright Dots: High Level to High Level
S ³ 15
S<15
Bright Dots: High Level to Low Level and
Low Level to Low Level
S ³ 5
S<5
Bright Dots: Two Adjacent Low Level
and Low Level (Any Plane)
N £ 2
N>2
Bright Dots Three or More Adjacent High or Low Level
(Horizontal Plane)
Not Allowed
Dark Dots
S ³ 15
S<15
Dark Dots: Two Adjacent (Horizontal
Plane Only)
N £ 2
N>2
Dim Lines Not Allowed
Cross Line(s) On/Off Not Allowed
Horizontal Line(s) On/Off Not Allowed
Vertical Lines(s) On/Off Not Allowed
Minimum Distance Between ANY
Allowable Defects
S ³ 25
(Unless Otherwise Specified
S<25
Maximum No. of Allowable Defects
N £ 5 (all types)
N>5
6. Audio
No audio function for HP L1502.
7. Mechanical characteristics
7.1 Tilt base
Tilt angle: -5 ° to +30 °
