Philips HTS8100 - Page 22

EN 22
3139 785 325404.
Dismantling Instructions & Service Positions
Summary of Dismantling Instructions (4.1.1 to 4.1.3)
Door Cover 200-49/Rear Cover 200-47
(Speaker Box Assembly Exploded View)
 Remove 10 screws
Ref: 4.1.1
HDMI 1060
 Remove 4 screws
Ref: 4.1.1
AVIO 1030/ SCART 1040
 Remove 2 screws
Ref: 4.1.1
HDMI Bracket 134
HDMI Assembly
 Remove 4 screws
Ref: 4.1.1
SD9.2 Mono Board 1070
 Remove 4 screws
Ref: 4.1.2
AVIO/SCART Bracket 135
AV Board 1020
 Remove 2 screws
Ref: 4.1.2
AV Assembly
 Remove 5 screws
Ref: 4.1.2
Rear Frame 132
PC Boards on the Rear Frame
- HDMI/AVIO/AV/SD 9.2
Rear Frame Assembly
 Remove 13 screws
Ref: 4.1.3
Door Board 1014
 Remove 1
screw
Motor and Gear Box
115+116+117+118+119+1090
Front Board
 Remove 3 screws
Ref: 4.1.3
Suspension Plate 129 & Traverse
Bracket 127
DVD mechanism 1080
 Remove 4 screws
Ref: 4.1.3
Door Board, Motor and Gear
Box Assembly
 Remove 4 screws
Ref: 4.1.3
DVD Assembly
 Remove 4
screws
Ref: 4.1.3
PC Boards on the lower level (Door/Front
Boards) and the DVD Mechanism
