Philips KV-S5055C - Page 85

85
8.5.32. Exit Roller
1. Remove the Conveyor 2. (See 8.5.30.)
2. Remove the Power Box. (See 8.5.6.)
3. Remove the Drive Belt. (See 8.5.11.)
4. Remove the Discharge Brush. (See 8.5.19.)
5. Pull out the Exit Roller in the direction of the arrow.
