5-4
5-4
ELECTRICAL PARTSLIST - KEY BOARD
- MISCELLANEOUS -
CN901 9965 000 18230 CONN 16P H P=1.0
LCD901 9965 000 18252 LCD MC320
LED901 9965 000 18253 LED WHITE
LED902 9965 000 18253 LED WHITE
LED903 9965 000 18254 LED GREEN
LED904 9965 000 18254 LED GREEN
LED905 9965 000 18254 LED GREEN
LED906 9965 000 18254 LED GREEN
LED907 9965 000 18304 LED BT-H203D-31 RED
SW901 4822 276 13775 SWITCH
SW902 4822 276 13775 SWITCH
SW903 4822 276 13775 SWITCH
SW904 4822 276 13775 SWITCH
SW905 4822 276 13775 SWITCH
SW906 4822 276 13775 SWITCH
SW907 4822 276 13775 SWITCH
SW908 4822 276 13775 SWITCH
SW909 4822 276 13775 SWITCH
SW910 4822 276 13775 SWITCH
SW911 4822 276 13775 SWITCH
SW912 4822 276 13775 SWITCH
SW913 4822 276 13775 SWITCH
- DIODES -
D901 4822 130 30621 1N4148
D903 4822 130 30621 1N4148
D904 4822 130 30621 1N4148
- IC & TRANSISTORS -
IC901 9965 000 18251 IC HT1622-64-QFP
IC902 9965 000 14545 SENSOR RECEIVER
Q905 5322 130 60159 BC846B
Note: Only these parts mentioned in the list are
normal service parts.
