Philips MC-320 - ELECTRICAL PARTSLIST - CD MCU BOARD; MISCELLANEOUS; RESISTORS; COILS & FILTERS

ELECTRICAL PARTSLIST - CD MCU BOARD
- MISCELLANEOUS - - IC & TRANSISTORS -
CN301 9965 000 18272 CONN 16P Q401 5322 130 44593 BC369
CN302 9965 000 18232 CONN 30P P=1.25 V Q405 4822 130 40981 BC337-25
CN303 9965 000 18273 CONN 9P Q406 4822 130 40981 BC337-25
CN304 9965 000 14709 TERMINAL PIN
CN401 9965 000 18274 CONN 22P
9965 000 18285 SWITCH SIDE SPVF130100
- RESISTORS -
RF301 9965 000 14537 1/2W 1Ω
- COILS & FILTERS -
L301 9965 000 16274 FIXED IND 100µH TP=52MM
L302 9965 000 16274 FIXED IND 100µH TP=52MM
L303 9965 000 16274 FIXED IND 100µH TP=52MM
L401 9965 000 18278 FIXED IND 10µH TP=26MM
L402 9965 000 18279 FIXED IND 47MH TP=26MM
L404 9965 000 18280 IND (AXIAL) 100MH 1.8Ω
L406 9965 000 18278 FIXED IND 10µH TP=26MM
L407 9965 000 18281 COIL 10µH
L408 9965 000 18281 COIL 10µH
L409 9965 000 18281 COIL 10µH
L410 9965 000 18281 COIL 10µH
L411 9965 000 18281 COIL 10µH
L412 9965 000 18281 COIL 10µH
X301 9965 000 18282 CRYSTAL 7.3728 MHZ
X302 9965 000 18283 CRYSTAL 32.768KHZ
X401 9965 000 18284 CER RESONATOR 16.93MHZ
- DIODES -
D301 4822 130 30621 1N4148
D302 4822 130 30621 1N4148
D303 4822 130 30621 1N4148
D403 4822 130 31878 1N4003G Note: Only these parts mentioned in the list are
D404 4822 130 31878 1N4003G normal service parts.
ZD401 4822 130 34173 BZX79-C5V6
- IC & TRANSISTORS -
IC301 9965 000 18275 IC MCU TMP87EP26F4K76
IC401 9322 171 88668 IC SM TA2153FN (TOSJ) R
IC402 9965 000 18276 IC TC9462F
IC403 9965 000 18277 IC TA2092N
Q301 5322 130 60159 BC846B
Q302 5322 130 60159 BC846B
Q303 5322 130 60159 BC846B
Q304 5322 130 44593 BC369
Q305 5322 130 44593 BC369
Q306 4822 130 60373 BC856B
!
