6-4 6-4
ELECTRICAL PARTSLIST - POWER BOARD
- MISCELLANEOUS -
CN701 9965 000 18244 CONN BASE 10P P=2.54
F701 9965 000 18245 FUSE 1.25A TSD 250V /21/37
F701 9965 000 11351 FUSE 800mA 250V /22/25/30
F703 9965 000 18246 FUSE 125mA TAPPING
F704 9965 000 18247 FUSE 6.3A TAPPING
F705 9965 000 18248 FUSE 3.15A TAPPING
PT701 9965 000 18302 POWER TRANS. EI-28 /22
RY701 9965 000 18303 RELAY /22/25
T701 9965 000 18249 FUSE CLAMP
T702 9965 000 18249 FUSE CLAMP
T703 9965 000 18250 CONNECTOR
T704 9965 000 18250 CONNECTOR
9965 000 11348 VOLTAGE SELECTOR 2P 5A /21
- CAPACITORS -
C701 9965 000 18300 CAP CER. 0.01MF 250V 20%/22/25
- COILS & FILTERS -
L701 9965 000 11379 FILTER MAINS 400µH
- DIODES -
D701 4822 130 30621 1N4148 /22/25
D702 4822 130 30621 1N4148 /22/25
D703 4822 130 30621 1N4148 /22/25
D704 4822 130 30621 1N4148 /22/25
D705 4822 130 30621 1N4148 /22/25
D706 4822 130 31878 1N4003G
D707 4822 130 31878 1N4003G
D708 4822 130 31878 1N4003G
D709 4822 130 31878 1N4003G
- IC & TRANSISTORS -
IC701 9965 000 18301 TA78057S /22/25
Q701 4822 130 40981 BC337-25 /22/25
Note: Only these parts mentioned in the list are
normal service parts.
!
!
!
!
!
!
!
!
!
!
!
