Tuner (FM)
Tuning Range 87.5 - 108MHz
Tuning grid 50KHz
Sensitivity
- Mono, 26dB S/N Ratio
- Stereo, 46dB S/N Ratio
<5 uV
>100 uV
Search Selectivity >28dB
Image rejection >25dB
Total Harmonic Distortion <3%
Signal to Noise Ratio >50dBA
Speakers
Speaker Impedance
-- L/R speaker
-- Subwoofer
4 ohm
4 ohm
Speaker Driver
-- L/R speaker
-- Subwoofer
3”
5”
Frequency Response 50 - 16000 Hz
10 Product
information
Note
Product information is subject to change without prior •
notice.
Specifi cations
Amplifi er
Rated Output Power 2 X 15W + 50W
RMS
Frequency Response
-- L/R speaker
-- Subwoofer
180 - 20000 Hz
50 - 180 Hz
Signal to Noise Ratio > 65dB
Aux Input 1V RMS 20k ohm
Disc
Laser Type Semiconductor
Disc Diameter 12cm/8cm
Video Decoding MPEG-1 / MPEG-2 /
DivX
Video DAC 12Bits
Signal System PAL / NTSC
Video Format 4:3 / 16:9
Video S/N >48dB
Audio DAC 24Bits / 96kHz
Total Harmonic
Distortion <0.1% (1 kHz)
Frequency
Response
4Hz - 20kHz (44.1kHz)
4Hz - 22kHz (48kHz)
4Hz - 24kHz (96kHz)
S/N Ratio >65dBA
