Philips MCM7/22 - SPECIFICATIONS; General Specifications; Tuner Specifications; Amplifier Specifications

1-3
SPECIFICATIONS
GENERAL:
Mains voltage : 110-127V/220-240V Switchable for /21/21M
120V for /37
220V for /33
220-230V for /22
230-240V for /30
Mains frequency : 50/60Hz
Power consumption : 80W at 1/8 P
rated
< 15W at Standby (Demo mode off)
< 0.5W at ECO Standby
Clock accuracy : < 4 seconds per day
Dimension centre unit : 175 x 252 x 350mm
TUNER:
FM
Tuning range : 87.5-108MHz
Grid : 50kHz
100kHz for /37
IF frequency : 10.7MHz ± 25kHz
Aerial input : 75 ohm coaxial
300 ohm click fit for /37
Sensitivity at 26dB S/N : < 7uV
Selectivity at 600kHz bandwidth : > 25dB
Image rejection : > 25dB [> 75dB]
Distortion at RF=1mV, dev. 75kHz : < 3%
-3dB Limiting point : < 8uV
Crosstalk at RF=1mV, dev. 40kHz : > 18dB
MW
Tuning range : 531-1602kHz
530-1700kHz for /21/21M/37
Grid : 9kHz
10kHz for /21/21M/37
IF frequency : 450kHz ± 1kHz
Aerial input : Frame aerial
Sensitivity at 26dB S/N : < 4.4mV/M
Selectivity at 18kHz bandwidth : > 18dB
IF rejection : > 45dB
Image rejection : > 28dB
Distortion at RF=50mV, M=80% : < 5%
AMPLIFIER:
Output power (6 ohm, 1kHz, 10% THD)
L & R : 2 x 50W RMS
Output power (6 ohm, 60Hz-12.5kHz, 10% THD)
L & R : 2 x 45W FTC /37
Frequency response within -3dB : 50Hz-16kHz
Bass : 60Hz ± 3 Steps
Treble : 12kHz ± 3 Steps
Incredible Surround : On / Off
Input sensitivity
Aux in (at 1kHz) : 500mV at 600 ohm
CDR in (at 1kHz) : 1000mV at 600 ohm
Output sensitivity
Headphone output at 32 ohm : 15mW ± 2dB (Max. vol.)
CD Headphone output at 32 ohm : 5mW ± 2dB (Max. vol.)
CASSETTE RECORDER:
Number of track : 2 tracks (stereo)
Tape speed : 4.76 cm/sec ± 2%
Wow and flutter : < 0.4% DIN
Fast-wind/Rewind time C60 : 130 sec
Bias system : 78kHz ± 10kHz
Rec/Pb frequency response within 8dB: 80Hz - 10kHz
Signal to Noise Ratio (Type I) : > 48dBA
Signal to Noise Ratio (Type II) : > 52dBA
COMPACT DISC:
Measurement done directly at the connector on the board.
Output Resistance : < 100 ohm
Output Voltage (0dB, 1kHz) : 0.5Vrms ± 1dB (unloaded)
Channel Unbalance : < ±1dB
Channel Separation (1kHz) : > 60dB
Frequency Response (±3dB) : 20Hz-20kHz
Signal to Noise Ratio : > 76dBA
MP3-CD Bit Rate : 32-256 kbps
Sampling Frequencies : 32, 44.1, 48 kHz
[....] Values indicated are for "ECO6 Cenelec Board" only.
