12-2 12-2
MECHANICAL & ACCESSORIES PARTS LIST - MAIN UNIT SCREW LISTS - MAIN UNIT
251 D2 x 8
252 D2 x 8
253 D2 x 8
254 D2 x 8
255 D3 x 20
256 D3 x 8
259 M3 x 12
260 D3 x 10
263 D3 x 12
264 D3 x 12
265 M3 x 12
266 M3 x 12
270 D3 x 35
271 M3 x 6
272 M3 x 10
273 M3 x 6
274 M3 x 10
275 D3 x 10
276 D3 x 10
277 D3 x 10
278 D3 x 10
279 M3 x 10
280 M3 x 10
281 D3 x 16
282 D3 x 12
283 D3 x 10
287 M3 x 10
289 D3 x 10
293 D2 x 8
0101 3139 254 00181 Cabinet Front /22
0101 3139 254 00351 Cabinet Front V2 /37
0110 3139 254 00441 Cover CD Technical UL Loader
0111 3139 254 00141 Cover CD
0121 3139 254 00171 Window Display /22
0121 3139 254 00681 Window Display /37
0125 3139 254 00131 Panel Control
0127 3139 254 00091 Button Set Power Chrome
0128 3139 114 79981 Lightguide Power Standby
0129 3139 254 00081 Button Set RDS/News
0132 3139 114 79921 Bracket Button RDS
0133 3139 254 00071 Button Set Source
0134 3139 114 79911 Cap Source Chrome
0135 3139 114 79971 Lightguide Source
0136 3139 254 00101 Button Set Function
0140 3139 254 00051 Knob Bass/Treble Chrome
0141 3139 254 00061 Knob Volume Chrome
0142 3139 254 00001 Lightguide Volume
0143 3139 114 79991 Lightguide IR
0144 4822 492 51374 Ring
0148 3139 254 00041 Frame Right
0149 3139 254 00031 Frame Left
0150 3139 254 00121 Cover Cassette
0151 3139 254 00111 Panel Cassette
0152 4822 459 10887 Badge Philips Assy
0155 3139 114 79941 Bracket Combi
0156 3139 114 79901 Bracket Module Mounting
0165 3139 113 27140 Foot Rubber 4mm
0166 3139 113 27140 Foot Rubber 4mm
0170 3139 114 73930 Door Cassette ETF SD Left
0171 4822 529 10322 Damper Assembly
0172 3139 114 68640 Push Catch Left
0173 4822 492 11344 Spring Compression
0174 4822 402 11245 Bracket Left
0175 3139 111 01390 Spring Torsion Left
0176 4822 492 42787 Spring Cassette
0180 3139 114 76040 Panel Left /22
0180 3139 114 75880 Panel Left V2 /37
0181 3139 114 76050 Panel Right /22
0181 3139 114 75890 Panel Right V2 /37
0192 3139 114 71010 Stopper Heatsink
0230 3139 254 00211 Panel Rear /22
0230 3139 254 00201 Panel Rear V2 /37
0240 3139 254 00581 Cover Top /22
0240 3139 254 00321 Cover Top V2 /37
0325 3139 119 02401 L/R Loudspeaker Box
0331 2422 076 00546 Cable FM Aerial /22
0331 4822 320 11094 FM Antenna Wire /37
0332 2422 549 45067 Antenna AM Loop
0333 3139 238 06511 Remote Control
0336 2422 070 98151
!
Mains Cord /22
0336 2422 070 98246
!
Mains Cord /37
1104 2822 031 01494 Fan 12VDC 0.8W 3100RPM
1106 3103 308 67611 PBAS 8 MP3CD03 TXT 5V
5001 3103 308 30780
!
Mains Transformer /22
5001 3103 308 30770
!
Mains Transformer /37
8001 3139 110 35900 FFC Foil 07P/220/07P AD
8003 3139 111 03871 FFC Foil 15P/280/15P BD Fold
8004 3103 308 93622 CWAS FFC 98 19P BD
8005 3139 110 35240 FFC Foil 08P/280/08P AD Fold
8006 3139 110 35080 FFC Foil 09P/180/09P AD
8007 3139 111 03881 FFC Foil 19P/180/19P AD Fold
8009 3139 110 34840 FFC Foil 08P/100/08P AD
8010 3140 110 20881 FFC Foil 15P/120/15P AD
8011 3139 110 35090 FFC Foil 04P/340/04P BD
8012 3139 110 34480 FFC Foil 07P/140/07P AD
8013 4822 320 12752 FFC Foil 07P/180/07P AD
Left/Right Loudspeaker Box Breakdown
9965 000 23631 Cloth Grille Assembly
9965 000 23632 Badge Philips
9965 000 23633 Grommet (Grey)
Note : Only the parts mentioned in this list are normal
service spare parts.
