11-8
11-8
MISCELLANEOUS
ELECTRICAL PARTS LIST - REGULATOR BOARD
ELECTRICAL PARTS LIST - COMBI BOARD
MISCELLANEOUS
1171 4822 071 51002
!
Fuse RAD LT 1A 250V
CAPACITORS
2402 2022 020 00625 220uF 20% 16V
2405 4822 124 11947 10uF 20% 16V
2406 4822 124 41643 100uF 20% 16V
2407 4822 124 41643 100uF 20% 16V
2408 2020 561 90365 100nF +80/-20% 50V
2409 4822 124 40248 10uF 20% 63V
2410 2020 561 90365 100nF +80/-20% 50V
2411 4822 124 12233 47uF 20% 25V
2418 4822 126 11714 4,7nF 20%
RESISTORS
3403 4822 050 11002 1k 1% 0,4W
3404 4822 116 52256 2k2 5% 0,5W
3405 4822 116 83876 270R 5% 0,5W
3406 4822 050 11002 1k 1% 0,4W
3411 4822 116 83883 470R 5% 0,5W
3415 4822 116 52199 68R 5% 0,5W
3416 4822 116 52206 120R 5% 0,5W
3417 4822 116 52206 120R 5% 0,5W
3418 4822 117 12063 NTC DC 5W 10k 5%
3419 4822 116 52219 330R 5% 0,5W
3420 4822 050 11002 1k 1% 0,4W
3421 4822 052 10568
!
5R6 5% 0,33W
3422 4822 050 21003 10k 1% 0,6W
DIODES
6400 4822 130 30621 1N4148
6401 4822 130 30621 1N4148
6405 4822 130 61219 BZX79-B10
6406 4822 130 34174 BZX79-C4V7
6409 4822 130 30621 1N4148
TRANSISTORS & INTEGRATED CIRCUITS
7401 4822 130 40959 BC547B
7402 4822 130 44568 BC557B
7403 9322 139 23687 TRA POW BDX53BFP
7408 4822 130 40959 BC547B
7409 4822 130 41246 BC327-25
7417 4822 209 31841 IC L7805CP
Note : Only the parts mentioned in this list are normal
service spare parts.
1001 4822 265 20553 Socket Cinch 2P - Aux in
1013 4822 265 11515 Flex Connector 8P
1014 4822 267 10733 Flex Connector 4P
1018 4822 265 10981 Flex Connector 15P
1022 4822 267 10953 Flex Connector 7P
1025 2422 025 14518 Flex Connector 9P
1026 4822 265 11553 Flex Connector 19P
1300 4822 252 11225
!
Fuse RAD LF 3,15A 250V
1301 4822 252 11225
!
Fuse RAD LF 3,15A 250V
1304 4822 267 10953 Flex Connector 7P
1307 4822 267 31176 Speaker Terminal 4P
CAPACITORS
2000 5322 126 11583 10nF 10% 50V
2003 2238 586 59812 100nF +80/-20% 50V
2006 2238 586 59812 100nF +80/-20% 50V
2011 2022 020 00734 1uF 20% 50V
2015 2022 020 00734 1uF 20% 50V
2023 2022 020 00734 1uF 20% 50V
2025 4822 126 13881 470pF 5% 50V
2027 2022 020 00734 1uF 20% 50V
2031 4822 126 13881 470pF 5% 50V
2032 4822 124 22651 1uF 20% 50V
2033 4822 124 23052 100uF 20% 16V
2038 2020 552 94427 100pF 5% 50V
2045 2020 552 94427 100pF 5% 50V
2046 4822 124 23052 100uF 20% 16V
2047 4822 124 81286 47uF 20% 16V
2048 2022 020 00734 1uF 20% 50V
2056 2022 020 00734 1uF 20% 50V
2058 4822 124 22651 1uF 20% 50V
2061 2020 552 94427 100pF 5% 50V
2062 2020 552 94427 100pF 5% 50V
2070 2238 586 59812 100nF +80/-20% 50V
2080 2022 020 00734 1uF 20% 50V
2081 2022 020 00734 1uF 20% 50V
2300 4822 124 12255 10uF 20% 50V
2301 4822 126 13193 4,7nF 10% 63V
2302 4822 126 13193 4,7nF 10% 63V
2303 4822 126 13193 4,7nF 10% 63V
2304 4822 126 13193 4,7nF 10% 63V
2305 3198 028 44790 47uF 20% 35V
2306 3198 028 44790 47uF 20% 35V
2307 4822 126 13193 4,7nF 10% 63V
2308 4822 126 13193 4,7nF 10% 63V
2309 4822 124 22651 1uF 20% 50V
2310 4822 124 22651 1uF 20% 50V
2311 4822 124 40207 100uF 20% 25V
2312 4822 124 40207 100uF 20% 25V
2313 4822 124 40207 100uF 20% 25V
2314 4822 124 40207 100uF 20% 25V
2315 4822 126 13193 4,7nF 10% 63V
2316 4822 126 13193 4,7nF 10% 63V
2317 2020 561 90365 100nF +80/-20% 50V
2318 2020 561 90365 100nF +80/-20% 50V
2319 4822 121 43526 47nF 5% 250V
2320 4822 121 43526 47nF 5% 250V
2321 4822 121 43526 47nF 5% 250V
2322 4822 121 43526 47nF 5% 250V
2324 4822 126 11785 47pF 5% 50V
2333 4822 124 40433 47uF 20% 25V
2334 4822 124 12255 10uF 20% 50V
2335 4822 124 12255 10uF 20% 50V
2336 4822 124 12255 10uF 20% 50V
2339 2238 586 59812 100nF +80/-20% 50V
2341 4822 124 40255 100uF 20% 63V
2341 2020 012 93664 100uF 20% 50V
2501 4822 126 13881 470pF 5% 50V
2502 4822 126 13881 470pF 5% 50V
2503 4822 126 13881 470pF 5% 50V
2504 4822 126 13881 470pF 5% 50V
2505 4822 126 13881 470pF 5% 50V
2506 4822 126 13881 470pF 5% 50V
2507 4822 126 13881 470pF 5% 50V
2508 4822 126 13881 470pF 5% 50V
2509 4822 126 13193 4,7nF 10% 63V
2510 4822 126 13193 4,7nF 10% 63V
2511 5322 124 41948 470nF 20% 50V
2512 5322 124 41948 470nF 20% 50V
2513 4822 121 42408 220nF 5% 63V
2514 4822 121 42408 220nF 5% 63V
2515 4822 121 51252 470nF 5% 63V
2516 4822 121 51252 470nF 5% 63V
2517 4822 121 51252 470nF 5% 63V
2518 4822 121 51252 470nF 5% 63V
2521 5322 126 11579 3,3nF 10% 63V
2522 5322 126 11579 3,3nF 10% 63V
2523 4822 126 14549 33nF 16V
2524 4822 126 14549 33nF 16V
2525 3198 016 31020 1nF 25V
2530 3198 016 31020 1nF 25V
2544 2020 552 94427 100pF 5% 50V
2545 2020 552 94427 100pF 5% 50V
2546 4822 126 14585 100nF 10% 50V
2547 4822 124 81286 47uF 20% 16V
2549 2238 586 59812 100nF +80/-20% 50V
2550 4822 124 40433 47uF 20% 25V
2551 4822 124 81151 22uF 50V
2552 2238 916 15641 22nF 10% 25V
2560 5322 124 41948 470nF 20% 50V
2563 2238 586 59812 100nF +80/-20% 50V
2700 2020 552 94427 100pF 5% 50V
2701 5322 121 42661 330nF 5% 63V
2702 4822 126 13881 470pF 5% 50V
MECHANICAL PARTS LIST
0202 4822 492 11735 SPRING TRANS
