Philips MCM760 - Electrical Partslist ECO6 Systems Non-Cenelec

MISCELLANEOUS
–––––––––––––––––––––––––––––––––––––––––––––––––––––
1101 2422 015 19376 SOCKET 2P CLICKFIT USA only
1102 4822 267 10283 SOCKET COAX, IEC 75Ω not USA
1103 4822 265 31184 JST CONNECTOR 2 POLE
1120 4822 265 11515 FFC SOCKET, 8P
CAPACITORS
–––––––––––––––––––––––––––––––––––––––––––––––––––––
2101 © 4822 126 13692 47pF 1% 63V
2102 © 4822 126 13838 100nF 10% 50V not USA
2103 © 5322 122 31647 1nF 10% 63V
2104 © 5322 122 32531 100pF 5% 50V
2105 © 4822 126 13838 100nF 10% 50V USA only
2106 2020 800 00191 3-11pF TRIMCAP.,N450
2107 4822 121 51319 1µF 20% 50V
2120 © 4822 126 13689 18pF 1% 63V
2124 © 5322 122 32654 22nF 10% 63V
2125 © 2020 552 96199 560pF 1% 50V
2126 © 5322 122 31863 330pF 5% 50V
2127 © 4822 126 14076 220nF 20% 25V
2128 4822 124 40248 10µF 20% 63V
2129 4822 124 41584 100µF 20% 10V
2130 © 5322 122 32654 22nF 10% 63V
2131 © 4822 126 13482 470nF 20% 16V
2132 © 4822 126 13482 470nF 20% 16V
2133 4822 124 21913 1µF 20% 63V
2134 © 4822 126 13188 15nF 5% 63V not USA
2134 © 5322 122 32654 22nF 10% 63V USA only
2135 © 4822 126 13188 15nF 5% 63V not USA
2135 © 5322 122 32654 22nF 10% 63V USA only
2136 © 4822 126 14076 220nF 20% 25V
2137 © 4822 126 14076 220nF 20% 25V
2138 4822 124 22652 2,2µF 20% 50V
2139 © 4822 126 14236 15pF 5% 50V
2140 © 4822 126 13695 82pF 1% 63V
2141 © 4822 126 13838 100nF 10% 50V
2143 © 4822 126 14076 220nF 20% 25V
2144 4822 124 21913 1µF 20% 63V
2145 © 4822 122 33575 220pF 5% 50V
2146 © 4822 122 33575 220pF 5% 50V
2147 © 4822 122 33575 220pF 5% 50V
2148 © 4822 122 33127 2,2nF 10% 63V
2149 © 5322 122 32659 33pF 5% 50V RDS only
2150 © 4822 126 13838 100nF 10% 50V
2152 © 4822 126 12105 33nF 5% 63V not for East Europe
2152 © 5322 116 80853 560pF 5% 63V for East Europe only
2153 © 4822 126 13486 15pF 2% 63V not for East Europe
2153 © 4822 122 33926 12pF 2% 50V for East Europe only
2155 2020 800 00191 3-11pF TRIMCAP.,N450
2159 © 5322 122 32659 33pF 5% 50V
2164 © 4822 126 13482 470nF 20% 16V
2165 © 4822 126 13838 100nF 10% 50V
2166 © 5322 122 31647 1nF 10% 63V
2167 © 4822 122 33926 12pF 5% 50V
2169 © 4822 122 33127 2,2nF 10% 63V RDS only
RESISTORS
–––––––––––––––––––––––––––––––––––––––––––––––––––––
3101 © 4822 051 20333 33kΩ 5% 0,1W
3102 © 4822 117 10837 100kΩ 1% 0,1W
3103 © 4822 051 20822 8,2kΩ 5% 0,1W
3104 © 4822 117 13577 330Ω 1% 0,1W
3105 © 4822 117 11503 220Ω 5% 0,1W
3132 © 4822 051 20479 47Ω 5% 0,1W
3134 © 4822 051 20223 22kΩ 5% 0,1W
3141 © 4822 117 11148 56kΩ 1% 0,1W
3142 4822 100 12159 TRIMPOT. 100kΩ
RESISTORS
–––––––––––––––––––––––––––––––––––––––––––––––––––––
3143 © 4822 051 20223 22kΩ 5% 0,1W RDS only
3144 © 4822 051 10102 1kΩ 2% 0,25W RDS only
3145© 4822 117 11449 2,2kΩ 1% 0,1W
3146 © 4822 051 20229 22Ω 5% 0,1W
3152 © 4822 051 20471 470Ω 5% 0,1W
3153 © 4822 051 20471 470Ω 5% 0,1W
3154 © 4822 117 13577 330Ω 1% 0,1W
3155 © 4822 117 11503 220Ω 5% 0,1W
3156 © 4822 117 10837 100kΩ 1% 0,1W
3157 © 4822 117 10837 100kΩ 1% 0,1W
3158 © 4822 051 20471 470Ω 5% 0,1W
3159 © 4822 051 20471 470Ω 5% 0,1W
3160 © 4822 051 20471 470Ω 5% 0,1W
3161 © 4822 051 20223 22kΩ 5% 0,1W
3167 © 4822 051 20121 120Ω 5% 0,1W
3168 © 4822 051 20121 120Ω 5% 0,1W
3169 © 4822 051 20154 150kΩ 5% 0,1W
3170 © 4822 117 10837 100kΩ 1% 0,1W
3172 © 4822 051 20562 5,6kΩ 5% 0,1W
3176 © 4822 051 20333 33kΩ 5% 0,1W RDS only
3181 © 4822 051 10102 1kΩ 2% 0,25W
4103 © 4822 051 20008 CHIP JUMPER 0805
4106 © 4822 051 20008 CHIP JUMPER 0805
4107 © 4822 051 20008 CHIP JUMPER 0805
4108 © 4822 051 20008 CHIP JUMPER 0805
COILS
–––––––––––––––––––––––––––––––––––––––––––––––––––––
5102 4822 157 71634 RF-COIL MW
5109 4822 242 70665 FM-IF FILTER 10,7MHz
5110 4822 242 70665 FM-IF FILTER 10,7MHz
5111 2422 549 44023 AM-IF FILTER 450kHz
5112 4822 157 70302 AM-IF FILTER 450kHz
5114 4822 157 70302 AM-IF FILTER 450kHz
5119 4822 157 11443 DISCRIMINATOR COIL
5121 4822 242 10261 QUARTZ 75kHz
5123 2422 549 44108 RF-COIL, AM-OSCILLATOR
5130 4822 157 11843 RF COIL 1,5 TURNS
5131 4822 157 11843 RF COIL 1,5 TURNS
DIODES
–––––––––––––––––––––––––––––––––––––––––––––––––––––
6103 © 5322 130 34337 BAV99
6105 © 4822 130 83075 HN1V02H
6106 © 4822 130 83757 BAS216
6107 © 9340 386 90115 BZX284-C11
6120 © 4822 130 83757 BAS216
6130 © 4822 130 82833 1SV228
6131 © 4822 130 82833 1SV228
TRANSISTORS
–––––––––––––––––––––––––––––––––––––––––––––––––––––
7102 4822 130 42131 BF550
7103 © 5322 130 42756 BC857C RDS only
7111 © 5322 130 42755 BC847C
7112 4822 130 44503 BC547C
INTEGRATED CIRCUITS
–––––––––––––––––––––––––––––––––––––––––––––––––––––
7101 © 9351 740 80557 TEA5757H/V1, RADIO IC
