Fig 36. Supply voltage ripple rejection
SVRR vs Freq
-80
-70
-60
-50
-40
0.1 1 10
F(kHz)
SVRR(dB)
Vp=14.4V
Rload=4ohms
Rin=0
Vripple=2Vp-p
