A: THD=10%
B: THD=0.5%
Fig 35. Pout vs. Vp at constant THD levels
Pout vs Vp
10
20
30
40
50
60
70
80
5 10 15 20Vp(V)
Po(W)
A
B
f=1kHz
Rl=4ohms
Clift=8200uF/16V
