Philips VR630 - Page 38

1-13-9 HC265-468TI
"H"
"Z"
"H"
"L" "L"
13 RF-SW
F-AD
(Internal Signal)
5 C-DRIVE
37 PB CTL
10 C-F/R
11 H-A-SW
12 ROTA
STILL STILL
AT
ST
BL
Stop detection (T2)
Acceleration Detection (T1)
Slow Tracking Value
Reversal Limit Value
FRAME ADVANCE
The first rise of RF-SW after a rise in F-AD signal
Fig. 4
