Philips VR630 - Parts and Packing Information; Electrical Parts Listing

ELECTRICAL PARTS LIST
Pos.
h
12 NC Description
MCV CBA 1
MCV CBA 1
MCV CBA 1
MCV CBA 1
MCV CBA 1
MCV CBA 1
MCV CBA 1
MCV CBA 1
Consists of the following
MAIN CBA (MCV-A CBA) 11111111
FUNCTION CBA (MCV-B CBA) 11111111
VPS CBA (MCV-C CBA) 11111111
POWER SW CBA (MCV-D CBA) 11111111
JACK CBA (MCV-E CBA) 11111111
SENSOR CBA 11111111
AFV CBA
MAIN CBA (MCV-A CBA) 11111111
2B7 9965 000 12286 SHIELD ASSEMBLY HC460ED 11111111
2B8 9965 000 08566 BUSH, LED(F) H3700UD 11111111
2B46 9965 000 12173 ROHM HOLDER H7770JD 11111111
AC001
h
9965 000 08666 AC CORD PE8B2CB1H0A-057 1 1 1 1 1 1
AC001
h
9965 000 12174 AC CORD PQ8B1V51H0A-05B 1 1
CAPACITORS
C002
h
9965 000 09743 METALLIZED FILM CAP. 0.068UF/250V M 11111111
C003
h
9965 000 06522 SAFETY CAP. 2200PF/250V 11111111
C004 9965 000 06566 ELECTROLYTIC CAP. 22UF/400V M(L?Z) or 11111111
C005 4822 126 14142 CERAMIC CAP. B K 0.01UF/500V 11111111
C006 4822 126 14141 CERAMIC CAP. SL K 56PF/1KV or 11111111
C007 CERAMIC CAP.(AX) X K 3300PF/16V 11111111
C008 CERAMIC CAP.(AX) X K 5600PF/16V 11111111
C010 FILM CAP.(P) 0.022UF/50V J or 11111111
C011 ELECTROLYTIC CAP. 10UF/16V M or 11111111
C012 ELECTROLYTIC CAP. 10UF/50V M H7 11111111
C014 ELECTROLYTIC CAP. 470UF/25V M or 11111111
C017 ELECTROLYTIC CAP. 470UF/16V M or 11111111
C018 ELECTROLYTIC CAP. 100UF/16V M or 11111111
C020 ELECTROLYTIC CAP. 1000UF/16V M 11111111
C021 ELECTROLYTIC CAP. 470UF/10V M or 11111111
C022 ELECTROLYTIC CAP. 22UF/50V M H7 1
C025 CERAMIC CAP.(AX) X K 5600PF/16V 11111111
C026 ELECTROLYTIC CAP. 47UF/16V M H7 11111111
C053 ELECTROLYTIC CAP. 330UF/6.3V M or 11111111
C056 CERAMIC CAP.(AX) F Z 0.047UF/16V 11111111
C060 ELECTROLYTIC CAP. 10UF/16V M H7 11111
C061 CHIP CERAMIC CAP. F Z 0.1UF/50V or 11111
C151 CHIP CERAMIC CAP. F Z 0.1UF/50V or 1
C152 CHIP CERAMIC CAP. F Z 0.1UF/50V or 1
C154 CHIP CERAMIC CAP. F Z 0.1UF/50V or 1
C155 ELECTROLYTIC CAP. 10UF/16V M H7 1
C156 ELECTROLYTIC CAP. 10UF/16V M H7 1
C157 ELECTROLYTIC CAP. 1UF/50V M H7 11111111
C158 CHIP CERAMIC CAP. B K 1000PF/50V or 11111111
C159 CHIP CERAMIC CAP. F Z 0.1UF/50V or 1
C251 ELECTROLYTIC CAP. 10UF/16V M H7 11111111
C252 CHIP CERAMIC CAP. B K 1000PF/50V or 11111111
C253 ELECTROLYTIC CAP. 1UF/50V M H7 11111111
C254 CHIP CERAMIC CAP. F Z 0.1UF/50V or 11111111
C302 CHIP CERAMIC CAP. B K 0.022UF/50V or 11111111
C303 ELECTROLYTIC CAP. 1UF/50V M H7 11111111
C304 ELECTROLYTIC CAP. 1UF/50V M H7 11111111
C305 CHIP CERAMIC CAP. F Z 0.1UF/50V or 11111111
C307 CHIP CERAMIC CAP. B K 0.047UF/50V or 11111111
C308 CHIP CERAMIC CAP. B K 0.022UF/50V or 11111111
C309 CHIP CERAMIC CAP. F Z 0.1UF/50V or 11111111
C310 CHIP CERAMIC CAP. B K 0.047UF/50V or 11111111
VR630/39 VR630/02 VR630/16 VR330/07 VR530/39 VR630/07 VR330/02 VR330/39
