12 NC Description
VR630/39
VR630/02
VR630/16
VR330/07
VR530/39
VR630/07
VR330/02
VR330/39
C11 CHIP CERAMIC CAP. B K 0.01UF/50V 11111
C12 ELECTROLYTIC CAP. 10UF/16V M H7 11111
C13 CHIP CERAMIC CAP. B K 0.01UF/50V 11111
C14 CHIP CERAMIC CAP. B K 0.01UF/50V 11111
C15 ELECTROLYTIC CAP. 10UF/16V M H7 11111
C16 ELECTROLYTIC CAP. 10UF/16V M H7 11111
C17 CHIP CERAMIC CAP. F Z 0.1UF/50V or 11111
C19 CHIP CERAMIC CAP. F Z 0.1UF/50V or 11111
C20 ELECTROLYTIC CAP. 3.3UF/50V M H7 11111
C21 CHIP CERAMIC CAP. F Z 0.1UF/50V or 11111
C22 ELECTROLYTIC CAP. 10UF/16V M H7 11111
C23 CHIP CERAMIC CAP. F Z 0.47UF/10V or 1 1
C24 ELECTROLYTIC CAP. 0.22UF/50V M H7 11111
CN1 ANGLE PIN HEADER, 9P 6029B-1-09Z003-T 11111
DIODES
D2 4822 130 30621 SWITCHING DIODE 1N4148M or 11111
IC1 9965 000 12199 IC:AUDIO PROCESSOR MSP3417G-QG-B8 or 1 1 1 1
IC1 9965 000 12274 IC:AUDIO PROCESSOR MSP3407G-QG-B8 or 1
COILS
L1 4822 157 10889 INDUCTOR 10UH-K-26T 11111
L2 4822 157 10332 PCB JUMPER D0.6-P5.0 11111
L3 4822 157 11318 INDUCTOR 18UH-K-26T 11111
L4 4822 157 10889 INDUCTOR 10UH-K-26T 11111
RESISTORS
R1 CHIP RES.(1608) 1/10W J 1K OHM 11111
R2 CHIP RES.(1608) 1/10W 0 OHM 1 1
R4 CHIP RES.(1608) 1/10W J 120K OHM 11111
R5 CHIP RES.(1608) 1/10W 0 OHM 11111
R6 CHIP RES.(1608) 1/10W 0 OHM 11111
R7 CHIP RES.(1608) 1/10W J 1.2K OHM 1 1
X1 9965 000 12200 X’TAL 18.432MHZ 11111
NOTES:
C… D…..±0.5% F …..±1%
G… J…..±5% K …..±10%
M… N…..±30% Z …..+80/-20%
PRODUCT SAFETY NOTE: Products marked with a
h
have special characteristics important to safety.
Before replacing any of these components, read carefully
the product safety notice in this service manual.
Don't degrade the safety of the product through improper servicing.
Parts that not assigned part numbers (-----------) are not
available.
Tolerance of Capacitors and Resistors are noted with
the following symbols.
To Next Page
