Philips VR630 - Page 55

ELECTRICAL PARTS LIST
Pos.
h
12 NC Description
VR630/39 VR630/02 VR630/16 VR330/07 VR530/39 VR630/07 VR330/02 VR330/39
C101 CHIP CERAMIC CAP. B K 2200PF/50V or 11111
C102 CHIP CERAMIC CAP. B K 2200PF/50V or 11111111
C103 CHIP CERAMIC CAP. CH J 470PF/50V or 11111
C104 CHIP CERAMIC CAP. CH J 470PF/50V or 11111111
C105 CHIP CERAMIC CAP. F Z 0.1UF/50V or 11111111
C107 ELECTROLYTIC CAP. 1UF/50V M H7 11111111
C108 CHIP CERAMIC CAP. B K 1000PF/50V or 11111111
C109 CHIP CERAMIC CAP. B K 2200PF/50V or 111111
C110 CHIP CERAMIC CAP. B K 2200PF/50V or 11111
C111 CHIP CERAMIC CAP. CH J 470PF/50V or 11111
C112 CHIP CERAMIC CAP. CH J 470PF/50V or 111111
C113 CHIP CERAMIC CAP. B K 2200PF/50V or 111111
C115 ELECTROLYTIC CAP. 100UF/16V M H7 11111111
C116 ELECTROLYTIC CAP. 470UF/6.3V M or 11111111
C117 ELECTROLYTIC CAP. 470UF/6.3V M or 111111
DIODES
D101 9965 000 12178 ZENER DIODE DZ-11BSAT265 or 11111111
D102 9965 000 12178 ZENER DIODE DZ-11BSAT265 or 111111
D103 9965 000 12178 ZENER DIODE DZ-11BSAT265 or 111111
D105 9965 000 12178 ZENER DIODE DZ-11BSAT265 or 11111111
JK101 9965 000 12197 RGB CONNECTOR MRC-021V-01 11111111
JK102 9965 000 12197 RGB CONNECTOR MRC-021V-01 111111
COILS
L101 4822 526 10685 BEAD CORE B16 RH 3.5X10X1.3 or 11111111
L121 4822 526 10685 BEAD CORE B16 RH 3.5X10X1.3 or 111111
TRANSISTORS
Q101 4822 130 42959 TRANSISTOR KTA1266(GR) or 11111111
Q102 4822 130 42959 TRANSISTOR KTA1266(GR) or 111111
RESISTORS
R101 CARBON RES. 1/4W J 1K OHM 11111111
R102 CARBON RES. 1/4W J 1K OHM 1 1 1
R103 CARBON RES. 1/4W J 1K OHM 11111
R104 CARBON RES. 1/6W J 4.7K OHM or 11111
R105 CARBON RES. 1/6W J 4.7K OHM or 1 1 1
R106 CARBON RES. 1/6W J 4.7K OHM or 11111111
R107 CHIP RES.(1608) 1/10W 0 OHM or 11111111
R108 CARBON RES. 1/4W J 68 OHM 11111111
R109 CHIP RES.(1608) 1/10W J 75 OHM or 11111111
R110 CARBON RES. 1/4W J 1K OHM 111111
R111 CARBON RES. 1/4W J 1K OHM 1
R112 CARBON RES. 1/4W J 1K OHM 11111
R113 CARBON RES. 1/6W J 4.7K OHM or 11111
R114 CARBON RES. 1/6W J 4.7K OHM or 1
R115 CARBON RES. 1/6W J 4.7K OHM or 111111
R116 CARBON RES. 1/6W J 15K OHM or 111111
R117 CHIP RES.(1608) 1/10W J 10K OHM or 111111
R118 CARBON RES. 1/4W J 68 OHM 111111
R119 CHIP RES.(1608) 1/10W J 75 OHM or 111111
R120 CARBON RES. 1/6W J 680 OHM or 11111111
R123 CHIP RES.(1608) 1/10W J 220 OHM or 11111111
R125 CARBON RES. 1/6W J 680 OHM or 111111
R126 CHIP RES.(1608) 1/10W J 220 OHM or 111111
R127 CHIP RES.(1608) 1/10W 0 OHM or 111111
R128 CHIP RES.(1608) 1/10W 0 OHM or 111111
SENSOR CBA 11111111
Q504 9965 000 08630 PHOTO TRANSISTOR PT204-6B-12 or 11111111
Q505 9965 000 08630 PHOTO TRANSISTOR PT204-6B-12 or 11111111
AFV CBA 11111
CAPACITORS
C1 CHIP CERAMIC CAP. F Z 0.1UF/50V or 11111
C4 CHIP CERAMIC CAP. CH J 56PF/50V or 11111
C5 CHIP CERAMIC CAP. CH J 22PF/50V or 11111
C6 CHIP CERAMIC CAP. CH J 56PF/50V or 11111
C7 CHIP CERAMIC CAP. CH D 3PF/50V or 11111
C8 CHIP CERAMIC CAP. CH D 3PF/50V or 11111
