12 NC Description
VR630/39
VR630/02
VR630/16
VR330/07
VR530/39
VR630/07
VR330/02
VR330/39
R852 CHIP RES.(1608) 1/10W J 1K OHM or 11111111
R853 CHIP RES.(1608) 1/10W J 1K OHM or 11111111
REMOTE RECEIVER
RS501 9965 000 12287 REMOTE RECEIVER MIM-93M9DKF or 11111111
SA001
h
4822 252 11373 SURGE ABSORBER JVR-10N471K 11111111
SWITCHES
SW501 4822 276 13954 TACT SWITCH KSM0614B or 11111111
SW502 4822 276 13954 TACT SWITCH KSM0614B or 11111111
SW504 4822 276 13954 TACT SWITCH KSM0614B or 11111111
SW505 4822 276 13954 TACT SWITCH KSM0614B or 11111111
SW506 9965 000 12285 LEAF SWITCH LSA-1142AU or 11111111
SW507 9965 000 08561 ROTARY MODE SWITCH SSS-43MD or 11111111
T001
h
9965 000 09203 PULSE TRANS SA-00901B 11111111
TP301 PCB JUMPER D0.6-P9.5 11111111
TP501 PCB JUMPER D0.6-P6.0 11111111
TP502 PCB JUMPER D0.6-P10.0 11111111
TP506 PCB JUMPER D0.6-P5.0 11111111
TP507 PCB JUMPER D0.6-P6.0 11111111
TP508 PCB JUMPER D0.6-P23.0 11111111
TP751 PCB JUMPER D0.6-P5.0 11111111
TU701 9965 000 12893 TUNER UNIT TMDG1-632A 1 1
TU701 9965 000 12901 TUNER UNIT TMDG1-635A 1
TU701 9965 000 12256 TUNER UNIT TMDZ2-731A 1 1 1
TU701 9965 000 12265 TUNER UNIT TMDG2-631A 1 1
VR501 9965 000 05260 CARBON P.O.T. 100K OHM B 11111111
X301 9965 000 05629 X’TAL 4.433619MHZ or 11111111
X501 9965 000 12194 X’TAL 12.000MHZ 11111111
X502 9965 000 12288 X’TAL 32.768KHZ(20PPM) or 11111111
FUNCTION CBA (MCV-B CBA) 11111111
CN651 ANGLE PIN HEADER, 3P 6029B-1-03Z002-T 11111111
R651 CHIP RES.(1608) 1/10W J 1K OHM or 11111111
R652 CHIP RES.(1608) 1/10W J 1.2K OHM or 11111111
R653 CHIP RES.(1608) 1/10W J 1.5K OHM or 11111111
R654 CHIP RES.(1608) 1/10W J 2.2K OHM or 11111111
R655 CHIP RES.(1608) 1/10W J 3.9K OHM or 11111111
SW651 4822 276 13954 TACT SWITCH KSM0614B or 11111111
SW652 4822 276 13954 TACT SWITCH KSM0614B or 11111111
SW653 4822 276 13954 TACT SWITCH KSM0614B or 11111111
SW654 4822 276 13954 TACT SWITCH KSM0614B or 11111111
SW656 4822 276 13954 TACT SWITCH KSM0614B or 11111111
VPS CBA (MCV-C CBA) 11111111
CAPACITORS
C640 CHIP CERAMIC CAP. F Z 0.1UF/50V or 11111111
C642 9965 000 12290 SEMICONDUCTOR CAP. SR K 0.056UF/25V or 11111111
C643 ELECTROLYTIC CAP. 4.7UF/25V M H7 11111111
C644 ELECTROLYTIC CAP. 47UF/6.3V M H7 11111111
C645 CHIP CERAMIC CAP. B K 0.01UF/50V or 11111111
C648 ELECTROLYTIC CAP. 1UF/50V M H7 11111111
C649 ELECTROLYTIC CAP. 1UF/50V M H7 11111111
IC’s
IC640 9965 000 12198 IC:VPS/PDC SLICER LC74793JM-TRM 11111111
RESISTORS
R638 CHIP RES.(1608) 1/10W J 100 OHM or 11111111
R641 CHIP RES.(1608) 1/10W J 10K OHM or 11111111
R642 CHIP RES.(1608) 1/10W J 2.7K OHM or 11111111
R643 CHIP RES.(1608) 1/10W J 5.6K OHM or 11111111
R644 CHIP RES.(1608) 1/10W J 10K OHM or 11111111
R645 CHIP RES.(1608) 1/10W J 10K OHM or 11111111
POWER SW CBA (MCV-D CBA) 11111111
SW510 4822 276 13954 TACT SWITCH KSM0614B or 11111111
JACK CBA (MCV-E CBA) 11111111
2L022 4822 502 30752 SCREW, P-TIGHT M3X10 WASHER HEAD+ 11111111
A5 9965 000 12894 JACK BOARD(1-21P) HC461BD or 1 1
A5 9965 000 12196 JACK BOARD(2-21P) HC460ED 111111
CAPACITORS
