ELECTRICAL PARTS LIST
Pos.
h
12 NC Description
VR630/39 VR630/02 VR630/16 VR330/07 VR530/39 VR630/07 VR330/02 VR330/39
R525 CHIP RES.(1608) 1/10W J 1.5K OHM or 11111111
R526 CHIP RES.(1608) 1/10W J 1.8K OHM or 11111111
R527 CHIP RES.(1608) 1/10W J 680 OHM or 11111111
R528 CHIP RES.(1608) 1/10W J 10K OHM or 11111111
R529 CARBON RES. 1/4W J 270 OHM 11111111
R530 CHIP RES.(1608) 1/10W J 180 OHM or 11111111
R531 CHIP RES.(1608) 1/10W J 68K OHM or 11111111
R533 CHIP RES.(1608) 1/10W J 33K OHM or 11111111
R534 CARBON RES. 1/6W G 3.6K OHM or 11111111
R535 CARBON RES. 1/6W G 10K OHM or 11111111
R536 CARBON RES. 1/6W G 470 OHM or 11111111
R537 CARBON RES. 1/6W G 22K OHM or 11111111
R538 CARBON RES. 1/6W G 1.5K OHM or 11111111
R539 CARBON RES. 1/6W G 4.7K OHM or 11111111
R540 CHIP RES.(1608) 1/10W J 390K OHM or 11111111
R541 CHIP RES.(1608) 1/10W J 390K OHM or 11111111
R542 CHIP RES.(1608) 1/10W J 1.2K OHM or 11111111
R543 CHIP RES.(1608) 1/10W 0 OHM or 11111111
R544 CHIP RES.(1608) 1/10W J 1.5K OHM or 11111111
R545 CHIP RES.(1608) 1/10W J 2.2K OHM or 11111111
R546 CHIP RES.(1608) 1/10W J 1.8K OHM or 11111111
R547 CHIP RES.(1608) 1/10W J 2.7K OHM or 11111111
R551 CHIP RES.(1608) 1/10W J 100 OHM or 11111111
R552 CHIP RES.(1608) 1/10W J 10K OHM or 11111111
R555 CHIP RES.(1608) 1/10W J 10K OHM or 1 1 1
R556 CHIP RES.(1608) 1/10W J 10K OHM or 1 1 1 1 1
R557 CHIP RES.(1608) 1/10W J 10K OHM or 1 1 1
R558 CHIP RES.(1608) 1/10W J 10K OHM or 1 1 1 1 1
R566 CHIP RES.(1608) 1/10W J 56K OHM or 11111111
R601 CHIP RES.(1608) 1/10W J 10K OHM or 1 1 1
R604 CHIP RES.(1608) 1/10W J 10K OHM or 1 1 1 1111
R605 CHIP RES.(1608) 1/10W J 10K OHM or 1111
R606 CHIP RES.(1608) 1/10W J 10K OHM or 1 1 1
R607 CHIP RES.(1608) 1/10W J 10K OHM or 111111
R609 CHIP RES.(1608) 1/10W J 10K OHM or 1 1
R610 CHIP RES.(1608) 1/10W J 10K OHM or 1 1111
R612 CHIP RES.(1608) 1/10W J 10K OHM or 11111111
R614 CHIP RES.(1608) 1/10W J 10K OHM or 1 1 1 1111
R615 CHIP RES.(1608) 1/10W J 10K OHM or 1111
R616 CHIP RES.(1608) 1/10W J 10K OHM or 1111
R619 CHIP RES.(1608) 1/10W J 10K OHM or 1 1
R620 CHIP RES.(1608) 1/10W J 1K OHM or 1
R701 CARBON RES. 1/6W J 1.8K OHM or 11111111
R702 CARBON RES. 1/6W J 1K OHM or 11111111
R703 CARBON RES. 1/6W J 1K OHM or 11111111
R706 CARBON RES. 1/6W J 1K OHM or 11111111
R709 PCB JUMPER D0.6-P5.0 1 1 1
R771 CHIP RES.(1608) 1/10W J 4.7K OHM or 11111111
R772 CHIP RES.(1608) 1/10W J 100K OHM or 11111111
R773 CHIP RES.(1608) 1/10W J 4.7K OHM or 11111111
R774 CHIP RES.(1608) 1/10W J 22K OHM or 11111111
R775 CHIP RES.(1608) 1/10W J 15K OHM or 11111111
R776 CHIP RES.(1608) 1/10W J 8.2K OHM or 11111111
R777 CHIP RES.(1608) 1/10W J 8.2K OHM or 11111111
R778 CHIP RES.(1608) 1/10W J 33K OHM or 11111111
R779 CHIP RES.(1608) 1/10W J 33K OHM or 11111111
R780 CHIP RES.(1608) 1/10W J 33K OHM or 11111111
R781 CHIP RES.(1608) 1/10W J 15K OHM or 11111111
R782 CHIP RES.(1608) 1/10W J 33K OHM or 11111111
R783 CHIP RES.(1608) 1/10W J 15K OHM or 11111111
R784 CHIP RES.(1608) 1/10W J 10M OHM or 11111111
R785 CHIP RES.(1608) 1/10W J 10M OHM or 11111111
R786 CHIP RES.(1608) 1/10W J 2.2K OHM or 11111111
R787 CHIP RES.(1608) 1/10W J 2.2K OHM or 11111111
R851 CHIP RES.(1608) 1/10W J 1.5K OHM or 11111111
