Philips VR630 - Vr530;39,Vr630;02,Vr630;07,Vr630;16,Vr630;39

1-13-8 HC265-468TI
[ VR530/39,VR630/02,VR630/07,VR630/16,VR630/39]
13 RF-SW
F-AD
(Internal Signal)
5 C-DRIVE
37 PB CTL
10 C-F/R
11 H-A-SW
12 ROTA
AT
"H"
"Z"
"H"
"L" "L"
ST
BL
STILL FRAME ADVANCE STILL
The first rise of RF-SW after a rise in F-AD signal
Stop detection (T2)
Slow Tracking Value
Acceleration Detection (T1)
Reversal Limit Value
Fig. 3
