1-14-5 HC478PIN
Notes:
Abbreviation for Active Level:
PWM -----Pulse Wide Modulation
A/D--------Analog - Digital Converter
85 IN LINK-IN
Easy Link Data
Input
Z/L
86 IN
P-
DOWN-L
Power Voltage
Down Detector
Signal
L
87 IN
C-FG
Capstan Motor
Rotation
Detection
Pulse
PULSE
88 -
AMPVss AMPVss (GND)
-
89 IN
D-FG
Drum Motor
Rotation
Detection Pulse
PULSE
90 IN
D-PG
Drum Motor
Pulse Generator
PULSE
91 -
N.U. Not Used
-
92 -
AMPVRE
F
IN
V-Ref for CTL
AMP
-
93 -
CC Terminal
-
94 OUT
CTL (-)
Playback/
Record Control
Signal (-)
H/L
95 OUT
CTL (+)
Playback/
Record Control
Signal (+)
H/L
96 -
AMPC
CTL AMP
Connected
Terminal
-
97 -
CTLAMP
out
To Monitor for
CTL AMP
Output
PULSE
98 -
AMPVcc AMPVcc
-
99 -
AVcc
A/D Converter
Power Input/
Standard
Voltage Input
-
100 IN
AGC
IF AGC Control
Signal
H/L/
Hi-z
Pin
No.
Mark
IN/
OUT
Signal
Name
Function
Active
Level
