ELECTRICAL PARTS LIST

Pos.

12 NC Description

VR732/02

VR732/39

VR730/07

VR730/39

VR732/16

VR730/02

VR730/16

C510 ELECTROLYTIC CAP. 22UF/10V M H7 1 1 1 1 1 1 1

C511 ELECTROLYTIC CAP. 100UF/6.3V H7 1 1 1 1 1 1 1

C512 CHIP CERAMIC CAP. F Z 0.1UF/50V 1 1 1 1 1 1 1

C513 CHIP CERAMIC CAP. CH J 22PF/50V 1 1 1 1 1 1 1

C514 CHIP CERAMIC CAP. CH J 22PF/50V 1 1 1 1 1 1 1

C515 CHIP CERAMIC CAP. CH D 10PF/50V 1 1 1 1 1 1 1

C516 CHIP CERAMIC CAP. CH D 10PF/50V 1 1 1 1 1 1 1

C517 CHIP CERAMIC CAP. B K 0.01UF/50V 1 1 1 1 1 1 1

C518 CHIP CERAMIC CAP. B K 0.047UF/50V 1 1 1 1 1 1 1

C519 CHIP CERAMIC CAP. B K 0.01UF/50V 1 1 1 1 1 1 1

C520 CHIP CERAMIC CAP. CH J 100PF/50V 1 1 1 1 1 1 1

C521 CHIP CERAMIC CAP. CH J 560PF/50V 1 1 1 1 1 1 1

C522 ELECTROLYTIC CAP. 22UF/6.3V M H7 1 1 1 1 1 1 1

C523 CHIP CERAMIC CAP. B K 1000PF/50V 1 1 1 1 1 1 1

C524 CHIP CERAMIC CAP. CH J 330PF/50V 1 1 1 1 1 1 1

C526 CHIP CERAMIC CAP. B K 4700PF/50V 1 1 1 1 1 1 1

C527 ELECTROLYTIC CAP. 22UF/6.3V M H7 1 1 1 1 1 1 1

C529 CHIP CERAMIC CAP. B K 0.01UF/50V 1 1 1 1 1 1 1

C530 CERAMIC CAP.(AX) F Z 0.022UF/25V 1 1 1 1 1 1 1

C531 CERAMIC CAP.(AX) Y M 0.01UF/16V 1 1 1 1 1 1 1

C535 CHIP CERAMIC CAP. B K 0.01UF/50V 1 1 1 1 1 1 1

C540 ELECTROLYTIC CAP. 470UF/6.3V M 1 1 1 1 1 1 1

C561 CHIP CERAMIC CAP. B K 0.022UF/50V 1 1 1 1 1 1 1

C622 CHIP RES.(1608) 1/10W 0 OHM 1 1 1 1 1 1 1

C701 CHIP CERAMIC CAP. B K 0.047UF/50V 1 1 1 1 1

C702 CHIP CERAMIC CAP. F Z 0.1UF/50V 1 1 1 1 1 1 1

C703 ELECTROLYTIC CAP. 10UF/16V M H7 1 1 1 1 1 1 1

C704 CHIP CERAMIC CAP. B K 0.01UF/50V 1 1 1 1 1 1 1

C706 CHIP CERAMIC CAP. B K 1000PF/50V 1 1 1 1 1 1 1

C707 ELECTROLYTIC CAP. 100UF/6.3V H7 1 1 1 1 1 1 1

C708 CHIP CERAMIC CAP. B K 0.01UF/50V 1 1 1 1 1 1 1

C715 CHIP CERAMIC CAP. B K 0.01UF/50V 1 1 1 1 1 1 1

C756 CERAMIC CAP.(AX) B K 470PF/50V 1 1 1 1 1 1 1

C757 CERAMIC CAP.(AX) B K 470PF/50V 1 1 1 1 1 1 1

C771 CHIP CERAMIC CAP. F Z 0.1UF/50V 1 1 1 1 1 1 1

C772 ELECTROLYTIC CAP. 10UF/16V M H7 1 1 1 1 1 1 1

C773 CHIP CERAMIC CAP. B K 1000PF/50V 1 1 1 1 1 1 1

C774 CHIP CERAMIC CAP. B K 1000PF/50V 1 1 1 1 1 1 1

C775 ELECTROLYTIC CAP. 1UF/50V M H7 1 1 1 1 1 1 1

C776 ELECTROLYTIC CAP. 1UF/50V M H7 1 1 1 1 1 1 1

C777 CHIP CERAMIC CAP. CH J 180PF/50V 1 1 1 1 1 1 1

C778 CHIP CERAMIC CAP. CH J 180PF/50V 1 1 1 1 1 1 1

C851 CHIP CERAMIC CAP. CH J 22PF/50V 1 1 1 1 1 1 1

C852 CHIP CERAMIC CAP. CH J 18PF/50V 1 1 1 1 1 1 1

C853 CHIP CERAMIC CAP. B K 4700PF/50V 1 1 1 1 1 1 1

C854 CHIP CERAMIC CAP. B K 0.01UF/50V 1 1 1 1 1 1 1

C855 CHIP CERAMIC CAP. F Z 0.1UF/50V 1 1 1 1 1 1 1

C856 CHIP CERAMIC CAP. CH J 180PF/50V 1 1 1 1 1 1 1

C858 CHIP CERAMIC CAP. CH J 560PF/50V 1 1

C859 ELECTROLYTIC CAP. 47UF/6.3V M H7 1 1 1 1 1 1 1

C862 CHIP CERAMIC CAP. B K 0.01UF/50V 1 1 1 1 1 1 1

CN506 9965 000 12262 FNT PCB ASSEMBLY CP2500/C470/FUNCTION 1 1 1 1 1 1 1

CN701 9965 000 12175 AFV PCB ASSEMBLY CP2500/C461 1 1 1

DIODES

D001 4822 130 31933 RECTIFIER DIODE 1N4005 1 1 1 1 1 1 1

D002 4822 130 31933 RECTIFIER DIODE 1N4005 1 1 1 1 1 1 1

D003 4822 130 31933 RECTIFIER DIODE 1N4005 1 1 1 1 1 1 1

D004 4822 130 31933 RECTIFIER DIODE 1N4005 1 1 1 1 1 1 1

D005 5322 130 34979 RECTIFIER DIODE BA159 1 1 1 1 1 1 1

D006 4822 130 30621 SWITCHING DIODE 1N4148M 1 1 1 1 1 1 1

D007 4822 130 30621 SWITCHING DIODE 1N4148M 1 1 1 1 1 1 1

D008 4822 130 30621 SWITCHING DIODE 1N4148M 1 1 1 1 1 1 1

D009 4822 130 30621 SWITCHING DIODE 1N4148M 1 1 1 1 1 1 1

1-16-16
