Philips VR730/07 - Electrical Parts List - Capacitors and Diodes; Capacitors List

NOTES:
C…..±0.25% D…..±0.5% F…..±1%
G…..±2% J…..±5% K…..±10%
M…..±20% N…..±30% Z…..+80/-20%
ELECTRICAL PARTS LIST
Pos.
h
12 NC Description
MCV CBA 1
Consists of the following 1 1 1 1 1 1
MAIN CBA(MCV-A) 1 1 1 1 1 1
FUNCTION CBA(MCV-B)
VPS CBA(MCV-C) 1 1 1 1 1 1
POWER SW CBA(MCV-D) 1 1 1 1 1 1
JACK CBA(MCV-E) 1 1 1 1 1 1
SENSOR CBA 1 1 1 1 1 1
SENSOR CBA 1 1 1 1 1 1
MAIN CBA 1 1 1 1 1 1
2B7 9965 000 12286 SHIELD ASSEMBLY HC460ED 1 1 1 1 1 1 1
2B8 9965 000 08566 BUSH, LED(F) H3700UD 1 1 1 1 1 1 1
2B46 9965 000 12173 ROHM HOLDER H7770JD 1 1 1 1 1 1 1
A4 9965 000 12261 JACK BOARD(CONV) HC460ED 1 1 1 1 1
AC001
h
9965 000 12174 AC CORD PQ8B1V51H0A-05B 1
AC001
h
9965 000 08666 AC CORD PE8B2CB1H0A-057 1 1 1 1 1 1
CAPACITORS
C002
h
9965 000 09743 METALLIZED FILM CAP. 0.068UF/250V M 1 1 1 1 1 1 1
C003
h
9965 000 06522 SAFETY CAP. 2200PF/250V 1 1 1 1 1 1 1
C004 9965 000 06566 ELECTROLYTIC CAP. 22UF/400V M(L?Z) 1 1 1 1 1 1 1
C005 4822 126 14142 CERAMIC CAP. B K 0.01UF/500V 1 1 1 1 1 1 1
C006 4822 126 14141 CERAMIC CAP. SL K 56PF/1KV 1 1 1 1 1 1 1
C007 CERAMIC CAP.(AX) X K 3300PF/16V 1 1 1 1 1 1 1
C008 CERAMIC CAP.(AX) X K 5600PF/16V 1 1 1 1 1 1 1
C010 FILM CAP.(P) 0.022UF/50V J 1 1 1 1 1 1 1
C011 ELECTROLYTIC CAP. 10UF/16V M 1 1 1 1 1 1 1
C012 ELECTROLYTIC CAP. 10UF/50V M H7 1 1 1 1 1 1 1
C014 ELECTROLYTIC CAP. 470UF/25V M 1 1 1 1 1 1 1
C017 ELECTROLYTIC CAP. 470UF/16V M 1 1 1 1 1 1 1
C018 ELECTROLYTIC CAP. 100UF/16V M 1 1 1 1 1 1 1
C020 ELECTROLYTIC CAP. 1000UF/16V M 1 1 1 1 1 1 1
C021 ELECTROLYTIC CAP. 470UF/10V M 1 1 1 1 1 1 1
C025 CERAMIC CAP.(AX) X K 5600PF/16V 1 1 1 1 1 1 1
C026 ELECTROLYTIC CAP. 47UF/16V M H7 1 1 1 1 1 1 1
C053 ELECTROLYTIC CAP. 330UF/6.3V M 1 1 1 1 1 1 1
C056 CERAMIC CAP.(AX) F Z 0.047UF/16V 1 1 1 1 1 1 1
VR732/02 VR732/39 VR730/07 VR730/39 VR732/16
Parts that not assigned part numbers (-----------) are not
available.
Tolerance of Capacitors and Resistors are noted with
the following symbols.
PRODUCT SAFETY NOTE: Products marked with a
h
have special characteristics important to safety.
Before replacing any of these components, read carefully
the product safety notice in this service manual.
Don't degrade the safety of the product through improper servicing.
VR730/02 VR730/16
1-16-13
