ELECTRICAL PARTS LIST
Pos.
h
12 NC Description
VR732/02 VR732/39 VR730/07 VR730/39 VR732/16 VR730/02 VR730/16
D011 4822 130 41487 RECTIFIER DIODE BA157 1 1 1 1 1 1 1
D012 4822 130 83883 RECTIFIER DIODE FR202 1 1 1 1 1 1 1
D013 4822 130 83883 RECTIFIER DIODE FR202 1 1 1 1 1 1 1
D014 4822 130 32715 SCHOTTKY BARRIER DIODE SB340 1 1 1 1 1 1 1
D015 9965 000 09323 ZENER DIODE DZ-9.1BSCT265 1 1 1 1 1 1 1
D018 4822 130 30621 SWITCHING DIODE 1N4148M 1 1 1 1 1 1 1
D019 9965 000 08622 ZENER DIODE DZ-5.6BSBT265 1 1 1 1 1 1 1
D021 4822 130 30621 SWITCHING DIODE 1N4148M 1 1 1 1 1 1 1
D051 4822 130 31933 RECTIFIER DIODE 1N4005 1 1 1 1 1 1 1
D052 4822 130 30621 SWITCHING DIODE 1N4148M 1 1 1 1 1 1 1
D053 9965 000 12176 RECTIFIER DIODE RL201 B-222-2 1 1 1 1 1
D056 9965 000 09182 ZENER DIODE DZ-5.1BSCT265 1 1 1 1 1 1 1
D057 9965 000 09283 ZENER DIODE DZ-10BSBT265 1 1 1 1 1 1 1
D151 9965 000 12177 ZENER DIODE DZ-6.8BSCT265 1 1 1 1 1 1 1
D152 9965 000 12177 ZENER DIODE DZ-6.8BSCT265 1 1 1 1 1 1 1
D153 9965 000 12178 ZENER DIODE DZ-11BSAT265 1 1 1 1 1 1 1
D154 9965 000 12178 ZENER DIODE DZ-11BSAT265 1 1 1 1 1 1 1
D155 9965 000 12178 ZENER DIODE DZ-11BSAT265 1 1 1 1 1 1 1
D156 9965 000 12178 ZENER DIODE DZ-11BSAT265 1 1 1 1 1 1 1
D301 4822 130 30621 SWITCHING DIODE 1N4148M 1 1 1 1 1 1 1
D370 4822 130 30621 SWITCHING DIODE 1N4148M 1 1
D501 4822 130 30621 SWITCHING DIODE 1N4148M 1 1 1 1 1 1 1
D502 9965 000 05250 LED SIR-563ST3F P 1 1 1 1 1 1 1
D552 4822 130 10094 ZENER DIODE MTZJT-777.5A 1 1 1 1 1 1 1
D553 4822 130 30621 SWITCHING DIODE 1N4148M 1 1 1 1 1 1 1
D701 9965 000 09183 ZENER DIODE DZ-33BSDT265 1 1 1 1 1 1 1
F001
h
9965 000 12179 FUSE 21301.6M 1 1 1 1 1 1 1
FH001 4822 256 10461 FUSE HOLDER MSF-015 1 1 1 1 1 1 1
FH002 4822 256 10461 FUSE HOLDER MSF-015 1 1 1 1 1 1 1
FP562 9965 000 09307 LED DISPLAY LFU-4421-2001A 1 1 1 1 1 1 1
IC’s
IC001
h
4822 130 11655 PHOTOCOUPLER LTV-817B-F 1 1 1 1 1 1 1
IC301 9965 000 12180 IC:Y/C/A LA71750AM-MTB 1 1 1 1 1 1 1
IC370 9965 000 12255 IC:SECAM LA70100M-TRM 1 1
IC451 9965 000 12181 IC:HIFI LA72646M 1 1 1 1 1 1 1
IC501 9965 000 12182 MICROCONTROLLER 16BIT M37762MFA-1B4GP 1 1 1 1 1 1
IC501 9965 000 12556 MICROCONTROLLER 16BIT M37762MFA-1B9GP 1
IC503 9965 000 06554 IC:MEMORY BR24C02F-W 1 1 1 1 1 1 1
IC561 9965 000 12183 IC:LED DRIVER PT6958-FN-TP 1 1 1 1 1 1 1
IC771 9965 000 12184 IC:COMPARATOR KIA339F EL 1 1 1 1 1 1 1
J902 4822 526 10685 BEAD CORE B16 RH 3.5X10X1.3 1 1 1 1 1 1 1
JK756 4822 265 11659 RCA JACK(YELLOW) MSP-281V4-B 1 1 1 1 1 1 1
JK757 4822 265 11661 RCA JACK(WHITE) MSP-281V1-B 1 1 1 1 1 1 1
JK758 9965 000 00423 RCA JACK(RED) MSP-281V3-A 1 1 1 1 1 1 1
JW001 9965 000 12185 FLAT CABLE, 11P 1 1 1 1 1 1 1
JW001 9965 000 12411 FLAT CABLE, 11P AWG26#2651/P1.25/150 1
JW002 9965 000 12186 FLAT CABLE, 12P 1 1 1 1 1 1 1
JW002 9965 000 12412 FLAT CABLE, 12P AWG26#2651/P1.25/150 1
JW003 9965 000 12187 FLAT CABLE, 2P 1 1 1 1 1 1 1
JW003 9965 000 12413 FLAT CABLE, 2P 1
COILS
L001 4822 526 10685 BEAD CORE B16 RH 3.5X10X1.3 1 1 1 1 1 1 1
L002 4822 526 10685 BEAD CORE B16 RH 3.5X10X1.3 1 1 1 1 1 1 1
L003
h
9965 000 12188 LINE FILTER 50MH LF-4Z-E503 1 1 1 1 1 1 1
L010 9965 000 05627 CHOKE COIL 47UH-K 1 1 1 1 1 1 1
L012 4822 157 10649 INDUCTOR 100UH-K-26T 1 1 1 1 1 1 1
L251 9965 000 08652 INDUCTOR 5.6UH-K-26T 1 1 1 1 1 1 1
L301 4822 157 63316 INDUCTOR 56UH-K-26T 1 1 1 1 1 1 1
L370 4822 157 10332 PCB JUMPER D0.6-P5.0 1 1
L401 9965 000 05627 CHOKE COIL 47UH-K 1 1 1 1 1 1 1
L402 9965 000 05627 CHOKE COIL 47UH-K 1 1 1 1 1 1 1
L451 4822 157 10649 INDUCTOR 100UH-K-26T 1 1 1 1 1 1 1
L452 4822 157 10347 INDUCTOR 22UH-K-26T 1 1 1 1 1 1 1
