Philips VR730/07 - Mechanical Parts List; Mechanical Assemblies and Front Parts

MECHANICAL PARTS LIST
Pos.
h
12 NC Description
A1X 9965 000 12257 FRONT ASSEMBLY HC471BD 1
A1X 9965 000 12264 FRONT ASSEMBLY HC472ED 1
A1X 9965 000 12266 FRONT ASSEMBLY HC473FD 1
A1X 9965 000 12267 FRONT ASSEMBLY HC475ED 1
A1X 9965 000 12277 FRONT ASSEMBLY HC477ED 1
A1X 9965 000 12278 FRONT ASSEMBLY HC478FD 1
A1X 9965 000 13004 FRONT ASSEMBLY HC470ED 1
A2 9965 000 12258 CASE, TOP HC470ED 1 1 1 1
A2 9965 000 12268 CASE, TOP(BLACK) HC475ED 1 1 1
A3 9965 000 12259 CHASSIS(U25PAL FTZ) HC470ED 1 1 1 1
A3 9965 000 12269 CHASSIS(435/BLACK) HC475ED 1 1 1
A7 9965 000 12260 PANEL, BOTTOM HC470ED 1 1 11111
A8 9965 000 12167 DOOR, CASSETTE HC466BD 1 1 1 1
A8 9965 000 12270 DOOR, CASSETTE HC475ED 1
A8 9965 000 12276 DOOR, CASSETTE HC476BD 1 1
A9 9965 000 09192 SPRING, DOOR H7220UD U15 1 1 11111
1B1 9965 000 12399 DECK ASSEMBLY CZD011/VM15E0 1 1 11111
2B5 9965 000 12168 SHEILD, CYLINDER HC460ED 1 1 11111
2B18 9965 000 12169 FIBER, TOP CASE H8101BD U15 PAL 1 1 11111
2L011 4822 502 13712 SCREW, P-TIGHT 3X12 BIND HEAD+ BLK 1 1 11111
2L021 4822 502 30752 SCREW, P-TIGHT M3X10 WASHER HEAD+ 1 1 11111
2L041 4822 502 14012 P-TIGHT SCREW 3X8 BIND + 1 1 11111
2L042 4822 502 14012 P-TIGHT SCREW 3X8 BIND + 1 1 11111
2L043 4822 502 14012 P-TIGHT SCREW 3X8 BIND + 1 1 11111
2L051 4822 502 14018 SCREW, S-TIGHT M3X5 BIND HEAD+ 1 1 11111
PACKING
S1 GIFT BOX CARTON HC471BD 1
S1 GIFT BOX CARTON HC470ED 1 1
S1 GIFT BOX CARTON HC475ED 1 1 1
S2 STYROFOAM HC461BD 1
S2 STYROFOAM HC460ED 1 11111
S3 UNIT, BAG E5500UD 1 1 11111
X1 9965 000 12172 REMOTE CONTROL UNIT 364/CRC006 1 1 1 1
X1 9965 000 12271 REMOTE CONTROL UNIT 364/CRC006 1 1 1
X3 9965 000 09742 RF CORD PAL 1.2M 1 1 11111
X4 ACCESSORY BAG K8092BA 1 1 11111
VR732/39
PRODUCT SAFETY NOTE: Products marked with a h
have special characteristics important to safety.
Before replacing any of these components, read carefully
the product safety notice in this service manual.
Don’t degrade the safety of the product through improper servicing.
VR730/07 VR730/39 VR732/16 VR730/02 VR730/16 VR732/02
1-18-2
