Philips VR730/07 - Deck Parts List; Deck Mechanism Components

DECK PARTS LIST DECK PARTS LIST
Pos.
h
12 NC Description Pos.
h
12 NC Description
B2 9965 000 12201
CYLINDER ASS.
MK11 PAL 4HD HIFI
B551 9965 000 12232 FF ARM(HI) MK10
B8 9965 000 12203 PULLEY ASSEMBLY MK11 B553 9965 000 12233 REV SPRING MK11
B10 9965 000 08431 MOVING GUIDE T PREP. MK10 B555 9965 000 12234 RACK ASSEMBLY MK11
B12 9965 000 12205 LOADING ARM S(B) ASS. MK11 B557 9965 000 08519 MOTOR PULLEY U5
B31 9965 000 12207 AC HEAD ASSEMBLY MK11 B558 9965 000 12235 LOADING MOTOR
B37 9965 000 12209 CAPSTAN MOTOR 288/VCCM011 B559 9965 000 12236 CLUTCH ASS. (HI)(2) MK11
B73 9965 000 12210 FE HEAD ASSEMBLY MK11 B560 9965 000 08522 KICK SPRING MK10
B73 9965 000 12896 FE HEAD ASSEMBLY MK11 B562 9965 000 08524 C DRIVE LEVER L MK10
B121 9965 000 12211 WORM MK11 B563 9965 000 08525 SLIDER SHAFT MK10
B133 9965 000 12213 IDLER ASSEMBLY(2) MK10 B564 9965 000 12237 M GEAR(HYT) N12G5F*
B300 9965 000 12214 C DRIVE LEVER R MK11 B565 9965 000 12238 SENSOR GEAR MK11
B347 9965 000 08445 GUIDE HOLDER A MK10 B567 9965 000 08544 PINCH ARM(B) MK10
B355 9965 000 12217 SLIDER L MK11 B568 9965 000 08545 BT ARM MK10
B410 9965 000 12218 PINCH ARM(A) ASSEMBLY MK11 B569 9965 000 12239 CAM HOLDER F MK11
B411 9965 000 08453 PINCH SPRING MK10 B570 9965 000 12240 CAM RACK SPRING(HI) MK11
B414 9965 000 12219 M BRAKE S(HI) ASSEMBLY MK11 B571 4822 532 13158 P.S.W F 6*2.55*0.5
B416 9965 000 12220 M BRAKE T(HI) ASSEMBLY MK11 B572 4822 532 13159 P.S.W CUT 1.6X4.0X0.5T
B417 9965 000 12221 TENSION SPG(190265) MK11 B573 9965 000 12241 REEL S MK11
B425 9965 000 08457 LOCK LEVER SPRING MK10 B574 9965 000 12242 REEL T MK11
B426 9965 000 08458 KICK PULLEY MK10 B578 9965 000 12243 TR GEAR A MK10
B482 9965 000 12222 C PLATE MK11 B579 9965 000 12244 TR GEAR B MK10
B483 9965 000 08461 LOCK LEVER MK10 B580 9965 000 12245 TR GEAR C MK11
B487 9965 000 08462 BAND BRAKE MK10 B581 9965 000 12246 CENTER GEAR(HYT) N12G5F*
B488 9965 000 12223 MODE LEVER(HI) MK11 B582 9965 000 12247 TR GEAR SPRING MK10
B491 9965 000 12224 CAM GEAR(A) MK11 B583 9965 000 05342 REEL WASHER MK9 5*2.1*0.5
B492 9965 000 12225 MODE GEAR MK11 B584 9965 000 12248 TR GEAR SHAFT MK10
B494 9965 000 12226 DOOR OPENER B MK11 B585 9965 000 12249 PSW(2957505) MK11
B499 9965 000 08467 T LEVER HOLDER MK10 L1051 9965 000 05359
SCREW, B-TIGHT
M2.6X6 PAN HEAD+
B501 9965 000 12227 WORM HOLDER MK11 L1053 9965 000 05375
SCREW, S-TIGHT
M2.6X8 WASHER HEAD+
B502 9965 000 08469 CAM GEAR(B) MK10 L1151 9965 000 08642
SCREW, SEMS
M2.6X4 PAN HEAD+
B505 4822 532 13158 P.S.W F 6*2.55*0.5 L1191 9965 000 05375
SCREW, S-TIGHT
M2.6X8 WASHER HEAD+
B507 9965 000 05342 REEL WASHER MK9 5*2.1*0.5 L1321 4822 502 14009
SCREW, S-TIGHT
M3X6 BIND HEAD+
B508 9965 000 08470 S BRAKE SPRING MK10 L1341 4822 502 14669
SCREW, P-TIGHT
M2.6X6 BIND HEAD+
B513 9965 000 08471 PSCW(752605) MK10 L1406 9965 000 08643 AC HEAD SCREW MK9
B514 9965 000 12228 SCREW RACK MK11 L1407 9965 000 12250
SCREW, S-TIGHT
M2.6X10 DISH HEAD+
B516 9965 000 05342 REEL WASHER MK9 5*2.1*0.5 L1450 4822 502 14671
SCREW, SEMS
M2.6X5 PAN HEAD+
B518 4822 532 13159 P.S.W CUT 1.6X4.0X0.5T L1461 4822 502 30471
SCREW, P-TIGHT
M2.6X6 WASHER HEAD+
B520 9965 000 12229 T BRAKE SPRING HI(F) MK11 L1466 9965 000 05364
SCREW, S-TIGHT
M2.6X6 BIND HEAD+
B521 9965 000 08482 SOFT SPRING MK10 L1467 9965 000 12251
SCREW, S-TIGHT
M2.6X5 WASHER HEAD+
B522 9965 000 08483 TG POST ASSEMBLY MK10 L1468 9965 000 12252
SCREW, B-TIGHT
M1.7X12
B525 9965 000 12230 LDG BELT MK11 L1471 9965 000 05364
SCREW, S-TIGHT
M2.6X6 BIND HEAD+
B529 9965 000 12231 CLEANER ASSEMBLY MK11
2-6-3
