For your safety
107708_en_09 PHOENIX CONTACT 11 / 104
• When installing and operating the device, observe the applicable regulations and safe-
ty directives (including national safety directives), as well as general technical regula-
tions. The safety-relevant data is included in this packing slip, the user manual and on
the certificates (manufacturer‘s declaration, additional approvals where applicable). All
documents can be downloaded at
phoenixcontact.net/product/2404267
.
• Observe the specified conditions for use in potentially explosive areas. Also observe
the requirements of EN 60079-14.
• Opening or modifying the device is prohibited. Do not repair the device yourself, but re-
place it with an equivalent device. Repairs may only be carried out by the manufacturer.
The manufacturer is not liable for damage resulting from non-compliance.
• The following work is only permitted in potentially explosive areas when the power is
disconnected:
– Snapping the device onto the DIN rail
– Removing the device from the DIN rail
– Connection and disconnection of cables
– Inserting and removing the SD card
• Connect the DIN rail to protective earth ground.
• Only connect one cable per terminal point.
• The switches of the device that can be accessed may only be actuated when the power
supply to the device is disconnected or when it has been ensured that there is no po-
tentially explosive atmosphere present.
• For safe operation, lockable plug connections must have a functional interlock (e.g.,
locking clip, screw connection, etc.). Insert the interlock. Repair any damaged connec-
tors immediately.
• For safe operation with the plug-in SD card, it must be completely plugged in and
snapped into place.
• For safe operation, all interfaces at the device must be used or covered.
• Please note the following derating values:
Table 1-1 Temperature derating of the AXC F 2152 depending on the altitude
Altitude
(above sea level)
Maximum ambient temperature
supply via bus base module
Maximum ambient temperature
with module AXC F PWR 1H
Up to 2000 m 55°C 60°C
2000 m ... 3000 m 49°C 54°C
3000 m ... 4000 m 44°C 48°C
4000 m ... 5000 m 38°C 42°C
