– This device must be installed in a tool only accessible enclosure certified for use in
Class I, Zone 2, minimum, and rated IP54, minimum, in accordance with
UL/CSA 60079-0 when used in a Class I, Zone 2 environment.
– Connect only one individual conductor per each clamping point, use conductors
24-16 AWG. Use only cables that are suitable for a temperature of at least 80°C.
– Electrical Ratings:
Input: U
L
= 24 V DC (19.2 V DC ... 30 V DC) / I
max
= 650 mA
Output: U
BUS
= 5 V DC / I
max
= 1 A
U
FAN
= 24 V DC (19.2 V DC ... 30 V DC) / I
max
= 0.04 A
– Use copper conductors only.
1.8 Notes on using the AXC F 2152 controller in poten-
tially explosive areas
Approval in accordance with ATEX directive 2014/34/EU and IECEx scheme
The category 3 device is designed for installation in zone 2 potentially explosive areas.
The device satisfies the requirements of EN/IEC 60079-0 and EN/IEC 60079-7.
Installation, operation, and maintenance must only be carried out by qualified electricians.
The IP20 degree of protection (IEC 60529/EN 60529) of the device is intended for use in a
clean and dry environment. Do not subject the device to mechanical and/or thermal loads
that exceed the specified limits.
The device must be stopped and immediately removed from the Ex area if it is damaged,
was subjected to an impermissible load, stored incorrectly or if it malfunctions.
The device is not designed for use in atmospheres with a danger of dust explosions.
This device must be installed in an area that is no longer classified as pollution degree 2 in
accordance with IEC 60664-1.
If this device is used in a zone 2 environment, it must be installed in a housing that at least
meets the requirements of IP54 degree of protection in accordance with IEC 60079-7 or an-
other degree of protection in accordance with IEC 60079-0, section 1.
• Follow the installation instructions as described.
Please note:
From 2020 on, the AXC F 2152 is available with approval for potentially explosive areas.
In this case, the approval is printed on the device.
• Before using the device in a potentially explosive area, make sure that your device
has the required approval.
The indicators and certificate numbers of the available approvals are printed on the de-
vice:
–
II 3 G Ex ec IIC T4 Gc
– TÜV 19 ATEX 8356 X
– IECEx TUR 19.0031X
WARNING: Explosion hazard
• Please make sure that the following notes and instructions are observed.
