Technical data
108997_en_04 PHOENIX CONTACT 105 / 226
5.22 FL SWITCH 2216
Immunity to EF EN 61000-6-2 EN 61000-4-3 (electromagnetic fields) Criterion
A
Immunity to ESD EN 61000-6-2 EN 61000-4-2 (ESD) Criterion B
Immunity to surge EN 61000-6-2 EN 61000-4-5 (surge) Criterion A
Immunity to conducted interference EN 61000-6-2 EN 61000-4-6 (line noise immunity) Criterion A
Conformity with EMC directives
Approvals / Certificates
ATEX II 3 G Ex ec IIC T4 Gc
IECEx Ex ec IIC T4 Gc
UL, USA UL 60079-0, Ed.6 / UL 60079-7, Ed.5
UL, Canada CSA C22.2 NO.60079-0, Ed.3 / CSA C22.2 NO.60079-7:16
UL, USA/Canada Class I, Div. 2, Groups A, B, C, D T4
Class I, Zone 2, IIC T4
Further approvals cULus Listed, EAC, ABS, BSH, DNV GL, LR, NK, RINA
Ordering data
Order designation FL SWITCH 2216
Order No. 2702904
Pcs./Pkt. 1
Dimensions (nominal sizes in mm)
Width 85 mm
Height 130 mm
Depth 115 mm
Ambient conditions
Degree of protection IP20
Protection class III, VDE 0106
Degree of pollution 2
Ambient temperature (operation) -40 °C ... 70 °C
Ambient temperature (storage/transport) -40 °C ... 85 °C
Permissible humidity (operation) 10 % ... 95 % (non-condensing)
Permissible humidity (storage/transport) 10 % ... 95 % (non-condensing)
Air pressure (operation) 79 kPa ... 108 kPa up to 2000m above mean sea level (Without
derating)
Air pressure (storage/transport) 79 kPa ... 108 kPa up to 2000m above mean sea level (Without
derating)
Free from substances that could impair the application of
coating
Yes
