FL SWITCH 2000 / FL NAT 2000
66 / 226
PHOENIX CONTACT 108997_en_04
5.7 FL SWITCH 2116
Immunity to ESD EN 61000-6-2 EN 61000-4-2 (ESD) Criterion B
Immunity to surge EN 61000-6-2 EN 61000-4-5 (surge) Criterion A
Immunity to conducted interference EN 61000-6-2 EN 61000-4-6 (line noise immunity) Criterion A
Conformity with EMC directives
Approvals / Certificates
UL, USA UL 61010-1, Ed.3 / UL 61010-2-201, Ed.1
UL, Canada CSA C22.2 NO.61010-2-201:14, Ed.1 / CSA C22.2 NO.61010-
1-12, Ed.3
Further approvals cULus Listed, EAC, CC-Link IE Field
Ordering data
Order designation FL SWITCH 2116
Order No. 2702908
Pcs./Pkt. 1
Dimensions (nominal sizes in mm)
Width 85 mm
Height 130 mm
Depth 115 mm
Ambient conditions
Degree of protection IP20
Protection class III, VDE 0106
Degree of pollution 2
Ambient temperature (operation) 0 °C ... 60 °C
Ambient temperature (storage/transport) -40 °C ... 85 °C
Permissible humidity (operation) 10 % ... 95 % (non-condensing)
Permissible humidity (storage/transport) 10 % ... 95 % (non-condensing)
Air pressure (operation) 86 kPa ... 108 kPa (1500m above sea level)
Air pressure (storage/transport) 86 kPa ... 108 kPa (1500m above sea level)
Free from substances that could impair the application of
coating
Yes
General data
Mounting type DIN rail
Type AX Book type
Functional earth ground The functional ground of the module is achieved when the
module is snapped onto the DIN rail.
Weight 435 g
