FL SWITCH 2000
54
PHOENIX CONTACT 107065_en_01
Global Status:
– Enable: port mirroring is activated globally
– Disable: port mirroring is deactivated globally
Destination Port: select the port to which the measuring device (PC) is connected here.
Mirrored Ports (Ingress): specify the ports from which the incoming data traffic should be
mirrored here.
Mirrored Ports (Egress): specify the ports from which the outgoing data traffic should be mir-
rored here.
5.2.3.7 Trap Manager
Figure 5-36 “Trap Manager” web page
Trap Mode:
– Enable: sending of SNMP traps is enabled
– Disable: sending of SNMP traps is disabled
Trap Server: all trap servers which are to receive SNMP traps from this device are displayed
here.
Add Trap Server: enter the IP address of a trap server and click on “Add&Save” to create
this trap server.
Test Trap Connection: the connection to the trap server is tested by clicking on the “Send
Trap” button.
The table lists the SNMP traps which can be sent by the device. Here you can select the
actions for which SNMP traps should be sent.
