IBSL SYS PRO UM E
1-14 6057AC01
1.5.2 Mounting Distances for INTERBUS Loop
Modules
Keep at least 150 mm (5.906 in.) (measured from the bottom edge of the
module) free between the module and a cabinet door or cover.
Figure 1-8 Mounting distances for modules
1 5 0 m m ( 5 . 9 0 6 " )
6 0 5 7 A 0 0 8
