Phoenix Model A26 INVADER GP - Installing the Main Landing Gear

A26 INVADER
Instruction Manual
10
< Left Wing >< Right Wing >
INSTALLING THE MAIN LANDING GEAR
< For Left > < For Right >
Assemble left and right
sides the same way
Apply threadlocker
(screw cement).
5x50mm Cap Screw
2
2
2
8
8
8
4x4mm Set Screw
4mm Washer
2
5mm Washer
4mm Spring Washer
4x25mm Cap Screw
6x4mm Aluminum
4
5x30mm Spring
5x45mm
4x4mm
5mm
6x4mm
100mm
