A26 INVADER
Instruction Manual
27
Assemble left and right
sides the same way.
Cut off excess.
INSTALLING THE GUN
Gun
8
3mm
3mm
3x12mm
3mm
Servo nose gear retract
Epoxy or silicone glue
31mm
20mm
20mm
31mm
Heating head
