Phoenix Model A26 INVADER GP - INSTALLING THE ELECTRIC MOTOR

A26 INVADER
Instruction Manual
40
RimFire .32
RimFire .32
RimFire .32
INSTALLING THE ELECTRIC MOTOR
3mm Washer
3mm Spring Washer
4 x 60mm Cap Screw
3mm Mount Nut
3 x 15mm Cap Screw
8
16
5mm Washer
16
10x35mm Aluminum
8
16
8
8
3x15mm
3mm
3x15mm
3mm
Must be purchased
separately!
Apply threadlocker
(screw cement).
White glue
4x60mm
5mm
4mm
10x35mm
