Phoenix Model A26 INVADER GP - Installing the Nose Gear Retract

A26 INVADER
Instruction Manual
24
INSTALLING THE NOSE GEAR RETRACT
2
2
2
3mm Washer
Apply threadlocker
(screw cement).
Aluminum ball
2
4
2
1000mm Cable rod
3x30mm Connector
Locknut
1
5x30mm Spring
3 x 12mm Screw
2
3mm Nylon Nut
2
5 x 35mm Cap Screw
1
1
1
4
4
4x4mm Set Screw
4mm Washer
1
5mm Washer
4mm Spring Washer
4
4 x 20mm Cap Screw
10x3mm Aluminum
< Wheel well >
Spring
Air Hose
Air Hose
5x35mm
5mm
10x3mm
4x4mm
65mm
