A26 INVADER
Instruction Manual
5
PREPARATIONS
Use a covering iron with a covering sock on
high heat to tighten the covering if necessary.
Apply pressure over sheeted areas to
thoroughly bond the covering to the wood.
INSTALLING THE AILERONS AND FLAPS
1. Test fit the ailerons to the wing with the hinges.
If the hinges don’t remain centered, stick a pin
through the middle of the hinge to hold it in
position.
2. Apply six drops of thin CA to the top and bottom
of each hinge. Do not use CA accelerator. After
the CA has fully hardened, test the hinges by
pulling on the aileron.
< Bottom view >
Assemble left and right
sides the same way
Assemble left and right
sides the same way
Main Wing
Flap
Flap
Aileron
Apply epoxy glue
