A26 INVADER
Instruction Manual
18
Apply threadlocker
(screw cement).
Cut off shaded portion
2
2
1200mm Cable rod
Locknut
1
Close or clamp pipe to fix position.
5x2mm
1
5x2mm
1
4mm Rod
