A26 INVADER
Instruction Manual
35
Assemble left and right
sides the same way
Adjust the throttle input (transmitter throttle stick), throttle trim movement and
the carburattor opening to the suitable position and screw in the 4x4mm set screw.
< Throttle Idling >
approx. 1mm
Carburetor
Throttle Servo
Throttle position of Tx.
< Throttle Hi > < Throttle Stop >
Must be purchased
separately!
Cut off shaded portion
Apply threadlocker
(screw cement).
Ensure smooth, non-binding
movement when assembling
4x4mm
