A26 INVADER
Instruction Manual
42
Cut off shaded portion
When rotating clock wise, change the
connection of 2 wires.
< Check the motor rotation >
Top Hatch
Open and Close
Adhesive tape
Gun
C.A glue
220mm
Cut off shaded portion
