MAIN GEAR ASSEMBLY
(2) Main gear aluminum
(2) 75mm diameter wheel
(2) Fiberglass wheel pant
(4) 4mm x 20mm socket head screw
(4) 8mm flat washer
(4) 4mm lock washer
(2) 16mm flat washer
(2) 8mm nut
(4) Collar
(4) 3mm x 4mm screw
(2) 4mm x 85mm axle
TAIL WHEEL ASSEMBLY
(1) Tail wheel bracket w/ wire
(1) 35mm diameter wheel
(2) 3mm collar
(2) 3mm screw
(2) Nylon control clasp
(3) 3mm x 12mm wood screw
ELEVATOR CONTROL SYSTEM
(1) 3mm x 170mm metal pushrod
(1) 3mm x 95mm metal pushrod
(2) M3 clevis
(2) 3mm x 50mm screw
(2) Set aluminum control horn
(2) Nylon horn
(2) Nylon ball link
(2) Aluminum ball
(2) 3mm x 12mm screw
(2) 6mm flat washer
(2) 3mm nut
1
KIT CONTENTS: We have organized the parts as they come out of the box for better identification
during assembly. We recommend that you regroup the parts in the same manner. This will ensure you
have all of parts required before you begin assembly.
KIT CONTENTS
THROTTLE CONTROL SYSTEM
(1) 1.3mm x 600mm wire
(1) 3.5mm x 350mm nylon
pushrod housing
(1) Metal connector
(1) 4mm x 4mm machine screw
FUEL TANK
(1) Nylon fuel Tank
(1) Metal clunk
(1) Pre - assembled stopper w / 3 tube
MISCELLANEOUS ITEMS
(1) 32mm x 680mm diameter
aluminum dihedral
(4) 6mm x 45mm nylon screw
(4) 2.6mm x 10mm wood screw
(2) 4mm x 30mm nylon screw
(2) 4mm x 35mm screw
(2) 8mm flat washer
(2) Plastic lock wing
YAK 54
Instruction Manual
RUDDER CONTROL SYSTEM
(1) 3mm x 120mm Metal pushrod
(1) M3 Clevis
(1) 3mm x 50mm screw
(1) Set aluminum control horn
(1) Nylon horn
(1) Nylon ball link
(1) Aluminum ball
(1) 3mm x 12mm screw
(1) 6mm flat washer
(1) 3mm nut
AILERON CONTROL SYSTEM
(2) 3mm x 95mm metal pushrod
(2) M3 Clevis
(2) 3mm x 50mm screw
(2) Set aluminum control horn
(2) Nylon horn
(2) Nylon ball link
(2) Aluminum ball
(2) 3mm x 12mm screw
(2) 6mm flat washer
(2) 3mm nut
MOTOR MOUNT ASSEMBLY
(4) 4mm x 25mm screw
(4) 4mm lock washer
(4) 8mm flat washer
(4) 4mm x 30mm screw
(4) 4mm lock washer
(8) 4mm nut
(2) Engine mount
