KIT CONTENTS: We have organized the parts as they come out of the box for better identification
during assembly. We recommend that you regroup the parts in the same manner. This will ensure you
have all of parts required before you begin assembly
AIR FRAME ASSEMBLIES
. (2) Wing halves with ailerons
. (1) Fuselage with canopy
. (1) Horizontal stabilizer with elevator halves
. (1) Vertical stabilizer with rudder
. (1) Cowling
. (1) Decal sheet
. (1) Instruction manual
MAIN GEAR ASSEMBLY
. (2) Main gear
. (2) 65mm diameter wheel
. (8) 2mm x 10mm wood screw
. (2) 5mm x 45mm machine screw
. (2) Collar
. (1) Set of alxe
. (2) M2 metal clevises
. (2) 1.7mm x 300mm metal pushrod
. (2) Silicone tube
. (2) Connector gear
. (2) Wood plate
. (4) 3mm x 6mm machine screw
. (4) 6mm flat washer
TAIL GEAR ASSEMBLY
. (1) Tail wheel bracket w/wire
. (1) 25mm diameter wheel
. (2) 2mm wheel collar
. (2) Nylon control clasp
. (2) 2mm x 16mm wood screws
ELEVATOR CONTROL SYSTEM
. (2) Control horn
. (4) 2mm x 12mm wood screw
. (2) M2 metal clevises
. (2) Silicone tube
. (1) Nylon snap keepper
. (1) Domino
. (1) 1.7mm x 100mm metal pushrod
RUDDER CONTROL SYSTEM
. (1) Control horn
. (2) 2mm x 30mm screw
. (1) M2 metal clevises
. (1) Silicone tube
. (1) Nylon snap keepper
AILERON CONTROL SYSTEM
. (2) Control horn
. (2) M2 metal clevises
. (2) Silicone tube
. (2) Nylon snap keepper
. (4) 2mm x 16mm wood screw
. (8) 2mm x 10mm wood screw
. (2) 1.7mm x 180mm metal pushrod
MOTOR MOUNT ASSEMBLY
. (1) Engine mount
. (4) 4mm x 20mm screw
. (4) 4mm flat washer
. (4) 8mm flat washer
. (4) 3mm x 20mm wood screw
. (4) 3mm flat washer
THROTTLE CONTROL SYSTEM
. (1) 1.3mm x 500mm wire
. (1) 3.5mm x 400mm nylon housing
. (1) Metal connector
FUEL TANK
. (1) Nylon fuel tank
. (1) Metal clunk
. (1) Pre - assembled stopper w/ 3 tube
MISCELLANEOUS ITEMS
. (1) Aluminum dihedral
. (4) Wing screw
. (2) 4mm x 30mm nylon screw
. (4) 2,6mm x 10mm wood screw
. (1) Spinner
. (1) Wood plate
. (3) 1.7mm x 700mm metal pushrod
. (1) Plastic plate
. (1) Cowling
. (1) Decal sheet
. (1) Instruction manual
KIT CONTENTS
1
