Phoenix Model GENESIS - Installing the Vertical Stabilizer; Installing the Tail Wheel

30
Hinges
29
INSTALLING THE VERTICAL STABILIZER
Repeat step 1 - step 5 from the installing aileron
for the installing rudder.
28
31
32
8
9. After the epoxy has fully cured, remove the
masking tape or T-pins used to hold the
stabilizer in place and carefully inspect the glue
joints. Use more epoxy to fill in any gaps that
were not filled previously and clean up the
excess using a paper towel and rubbing alcohol.
10. Repeat step 1 - step 5 from the installing
aileron for the installing elevator.
27
Glue the hinges
by C.A glue
INSTALLING THE TAIL WHEEL
1. Using the knife cut away the wood from the
bottom of the rudder and slide the two nylon
clasps into the slot. Using C.A glue the nylon
clasps as shown.
