Phoenix PHX-200 - Page 41

PG.41
NC
NO
#14
-FROM BLACK DIST. M
ANIFOLD
#52-FROM CONTOL AIR
REGULATOR ASSY OUTLET
1
54
#37-TO "OR" VAL
VE PORTa
#29-TO SCREE
N VALVE INLET
#36-F
ROM 4 WAY MANIFOL
D ELBOW
#44-FROM YELLOW
MANIFOLD
#1-FROM PILOT FIL
TER
58
37 29
14 28
36
4
4
2
3
3
SEE DISTRIBUTION
SEE CONTROL SHELF
30140-TUBEC PHX-200 TUBE DIAGRAM SHEET 2 OF 4 CONTROL PANEL AND E-STOP
53
PI-2
CV5
REG1
PI-3
REG5
CK1
RES2
PI-1
VB3 VB4
TO AUGER MOTOR LUBRICATOR
NO
# 27 FROM ARM OR VALVE PORT A
VB2
NO
# 24 TO ENABLE YES
VALVE PORT X
VB1
# 16 FROM BLACK MANIFOLD
#2-TO SHUTT
LE VALVE INLET
28
#55-TO AUGER DRIVE MOTOR LUBRICATOR
SEE FRAME MOUNTED COMPONENTS
